Chapter 8: Digital and Timer-Controlled I/O

Overview of Available Digital I/O

The QVGA Controller provides 30 digital I/O lines, 24 analog I/O lines, and three communications channels.  The digital I/O lines originate in four ports on the CPU (68HC11), designated PORTA, PORTB, PORTC, and PORTD, and three additional ports provided by a peripheral interface adapter (PIA) chip (82C55A), designated PPA, PPB and PPB.  Table 8‑1 summarizes the digital I/O available, its alternate uses, and port assignments.

Table 8‑1   The QVGA Controller’s Digital I/O

I/O Lines

Type

Port Address

Comments / Alternate Uses

8

Configurable either as all digital inputs or outputs

PPA 0-7

Initialized on start-up and resets as inputs.

5

Digital outputs

PPB 0-4

Initialized as outputs, but if the high-current drivers that use PPB 5-7 are not needed, PPB may be software reconfigured to all inputs.

4

Open-drain high-current outputs

PPB 5-7 and PAL bit



4

Digital inputs

PPC 0-3

Initialized on start-up and resets as inputs, but may be reconfigured as all outputs.

3

Configurable either as all digital inputs or outputs

PPC 5-7

Initialized as inputs but if RS485 is used PPC5-7 must be reconfigured as outputs.

6

Timer-controlled inputs or outputs including 3 input-capture, 3 output-compare, and pulse accumulator

PA 0-2, 5-7

Bit-by-bit configured by the application as inputs or outputs, including:
          Timed inputs:   PA 0-2
       Timed outputs:   PA 5-7
Pulse accumulator:  PA 7

30

Digital I/O lines





There are a total of 30 fully uncommitted digital I/O lines for your use.  After initialization or reset these are configured as 21 digital inputs and 9 digital outputs, but as Figure 8‑1 shows many of these I/O lines are reconfigurable.  Up to 21 of these I/O lines can be configured as inputs, all can be configured as outputs.

In addition to these I/O lines there are several committed to other services on the controller; these are summarized in Table 8‑2.

Table 8‑2      Committed I/O pins

Service

Port

Pins

RS-485

PIA PPC

PPC 4

8-bit A/D

CPU PORTE

PE 0-7

Serial 2

CPU PORTA

PA 3-4

SPI

CPU PORTD

PD 2-5

For applications requiring even more digital I/O, I/O lines usually committed to the 8-bit A/D, the RS485 port, the secondary serial port or the SPI may be redirected as general purpose digital I/O if these other services are not needed, providing up to 15 additional digital I/O lines.  Table 8‑3 summarizes the digital I/O lines gained if other services are not used.  The services uses are ordered from the least-used (the RS485) to the most frequently used (the SPI).  Note that the SPI is required to use the 12-bit A/D and any Wildcard I/O expansion modules.  The five of the 9 output lines that originate on PPB (PPB 0-4) may be converted to input lines if the high current drivers are not needed.  In that case, PPB can be reconfigured as all inputs, 9 outputs can be traded for 5 inputs, for a loss of 4 total lines but a gain of 5 more inputs.

Table 8‑3      Additional digital I/O lines made available if other services are forfeited and their committed I/O pins freed.

Services Used

Digital I/O Available

RS485

8-bit A/D

Serial 2

SPI

Inputs

Outputs

Total

Initial

Max

Initial

Max

Yes

Yes

Yes

Yes

21

21

9

30

30

No

Yes

Yes

Yes

22

22

9

31

31

No

No

Yes

Yes

30

30

9

39

39

No

No

No

Yes

32

32

9

41

41

No

No

No

No

36

36

9

45

45

Many of these 57 I/O lines are digital inputs and outputs.  Including the high current drivers the maximum number of digital inputs and outputs is 41 (up to 32 can be configured as inputs, up to 29 as outputs) if none are used for the 8-bit A/D, the RS485, or the secondary serial port.  Table 8‑1  summarizes the digital I/O and alternate use of some of the I/O pins.

Digital inputs and outputs are very useful in data acquisition, monitoring, instrumentation and control applications.  A low voltage (approximately 0 Volts) is established on a digital output pin when the processor writes a logical 0 to the corresponding bit in a data register associated with the digital output port.  A high voltage (approximately 5 Volts) is established on the digital output pin when the processor writes a 1 to a corresponding bit in the port’s data register.  This allows software to control external events and processes.  For example, an application program can use digital outputs to activate solenoids and turn switches and lights on and off, or to interface the QVGA Controller with a wide variety of digital accessories.

A digital input allows the processor to monitor the logical state of an external voltage by reading a data register associated with the port.  External voltages near 0 Volts connected to a digital input cause the corresponding bit in the port’s data register to be read as a logical 0, and external voltages near 5 Volts connected to a digital input are read as a logical 1.  Application programs can use digital inputs to read switches and keypads or to interface to digital devices such as A/D converters and real-time clocks.

In addition, there are four high current drivers available.  These N-channel MOSFET outputs can sink 150 mA continuously, and up to 1 amp on an intermittent basis.  Onboard snubber diodes allow control of inductive loads.  They are particularly useful for driving relays, solenoids, and low power stepper motors.

Using digital I/O is very easy: simply configure the output port as input or output as explained below, and then use functions or assignment statements to read from or write to the port.  The names of the data and direction registers and all required initialization routines are pre-defined in the header files so you don’t have to worry about hexadecimal register addresses in your code.

The following sections describe the available digital I/O ports and how to use them.

The digital I/O signals on the QVGA Controller originate from a Motorolla 68HC11 processor chip and an 82C55A peripheral interface adapter (PIA) chip.  The 68HC11 provides two 8 bit ports named PORTA and PORTE, and 4 available bits on PORTD (PD2 through PD5).  The PIA supplies three 8 bit digital I/O ports named PPA, PPB, and PPC.

Table 8‑4  summarizes the digital input/output available on the QVGA Controller including the names, addresses, and number of signals associated with the digital ports on the 68HC11 and PIA.  The “configurable as” column specifies whether the direction of the port may be changed on a bit-by-bit, nibble-by-nibble, or byte basis (or in the case of PORTE, configured as digital or analog input). The final column lists alternate uses (other than standard digital I/O), the signal pins and the number of signals associated with the alternate uses.  Note that a fourth High Current driver output is controlled by the onboard PAL.

Table 8‑4      Digital I/O Port Addresses and Configurability.

Port Name

Address (HEX)

I/O Line

Configurable As

     Alternate Use    (Signals Used)

68HC11:









PORTA

8000

8

Bitwise I/O

                     Serial2:   PA3 & PA4  (2)
Pulse accumulator:  PA7              (1)
          Timed inputs:   PA0-3       (3 or 4)
       Timed outputs:   PA3-7       (4 or 5)

PORTD

8008

4

Bitwise I/O

SPI controls AD12 & DAC             (4)

PORTE

800A

8

Bytewise digital or analog input

                   8 bit A/D:   PE0-7          (8)

PIA:









PPA

8080

8

Bytewise I/O



PPB

8081

8

Bytewise I/O

High Current Outs:   PPA5-7        (3)

PPC lower

8082

4

Nibblewise I/O

        Keypad Inputs:   PPC0-3       (4)

PPC upper

8082

4

Nibblewise I/O

                     RS485:   PPC4           (1)

Table 8‑5  specifies the named data direction register which controls the input/output direction, or specifies the functions that configure each digital I/O port.

Table 8‑5      Digital I/O port data direction registers and configuration functions.

Port Name

Configured By

68HC11:



PORTA

DDRAPORTA.DIRECTION

PORTD

DDRDPORTD.DIRECTION

PORTE

AD8On()
AD8Off()
A/D8.ON
A/D8.OFF

PIA:



PPA

InitPIA()INIT.PIA

PPB

InitPIA()INIT.PIA

PPC lower

InitPIA()INIT.PIA

PPC upper

InitPIA()INIT.PIA

Alternate Uses of the Digital I/O Ports

Some of these port signals have alternative uses as summarized in Table 8‑4 .  The 68HC11’s I/O ports and the PIA ports can serve a variety of selectable functions:

[[[Figure  1.2 summarizes the digital and analog I/O available on the QED Board.  It specifies the origin of the signals, their type and configurability, and the number of signals dedicated to alternate uses. The following text explains the contents of Figure 1.2.

The 24 I/O lines originating at the PIA are named Peripheral Port A (PPA), Peripheral Port B (PPB), and Peripheral Port C (PPC).  PPA is an 8 bit digital I/O port available for the user’s application; it can be configured as either input or output.

PPB is an 8 bit digital port dedicated to the built-in keypad/display interface (PPB0 to PPB6) and to the generation of the chip select signal for the optional 12 bit A/D (PPB7).  It is configured as an output port by QED-Forth.

PPC is split into two 4 bit digital I/O ports called lower PPC (PPC0 to PPC3) and upper PPC (PPC4 to PPC7).  Lower PPC is used to scan the keypad.  If RS485 communications is not in use, all of upper PPC is available for the user’s application; it can be configured as either input or output.  If RS485 is being used, one bit in upper PPC (PPC4) is dedicated to controlling the direction of data transfer, and the remaining three output bits (PPC5 to PPC7) are available for the user’s application.

As shown in Figure 1.2, the 68HC11’s PORTA is an 8 bit digital I/O port configurable as input or output on a bit by bit basis.  These signals can also be used to implement input captures (PA0 to PA3), output compares (PA3 to PA7), and a pulse accumulator (PA7).  The secondary serial port, if used, ties up two of the PORTA lines (PA3 and PA4) to implement the receive and transmit signals.

PORTD on the 68HC11 contains 4 digital I/O bits (PD2 to PD5) that implement the fast serial peripheral interface (SPI).  If the SPI is not in use (which implies that the 12 bit A/D and 8 bit DAC are not on the board), these four lines are available as general purpose inputs or outputs.

The final three entries in the table in Figure 1.2 present the analog I/O ports on the QED Board.  PORTE on the 68HC11 implements the 8 channel 8 bit A/D.  If this A/D is not in use, PORTE can be configured as an 8 bit digital input port.  The optional 8 channel (or 4 channel differential) 12 bit A/D provides 8 analog inputs, and the optional 8 channel 8 bit DAC provides 8 analog outputs.  As explained in Chapter 6, pairs of DACs may be combined to achieve higher resolution digital to analog conversion.]]]

PORTA

PORTA may be used as bit-configurable digital input/output.  The data direction (input or output) of each bit in PORTA is determined by writing to the DDRA register as described below.  If any bits in PORTA are not being used for simple digital I/O, they may be used to implement a variety of counting and timing functions including input captures, output compares, and pulse accumulation.  In addition, the QED Board provides an optional software UART that supports a secondary RS232 serial port (called serial2) using pins 3 and 4 of PORTA.

PORTD

PORTD is a 6 bit port that is typically dedicated to serial I/O (PD0 and PD1) and to the Serial Peripheral Interface (PD2-PD5).  The SPI is a fast synchronous serial link which is used to communicate with the optional onboard 12 bit analog to digital converter (A/D12) and 8 bit digital to analog converter (DAC).  The SPI is turned on by executing InitSPI() or InitAD12andDAC() and is turned off by executing SPIOff().  The SPI is initially off after a reset or restart.  If you have ordered a custom board with no 12 bit A/D or DAC, you may use PD2-PD5 as 4 general purpose digital I/O bits whose data direction is set by register DDRD and whose contents are accessible at register PORTD.

PORTE

PORTE provides 8 input lines.  They may be used as the analog inputs to the 68HC11’s built-in 8 bit A/D converter, or they may be used as general purpose digital inputs if the 8 bit A/D converter is turned off.  The AD8On() function turns the 8 bit A/D on, and AD8Off() turns it off.  The 8 bit A/D is initially off after a reset or restart.

PPA

PPA has no alternate functions and is available as a general purpose digital input port or output port.

PPB

Three bits of PPB are dedicated to controlling three of the open-drain high-current drivers.  The remaining 5 lines are available for your use .

PPC

The upper 4 bits of PPC are available as digital input or output if RS485 communications are not being used.  If RS485 communications are used, bit 4 of PPC (that is, the lowest bit in the upper nibble of PPC) controls the direction of the RS485 transceiver, and the upper half of PPC must be configured as an output (see the Glossary entry for InitRS485).

Using the Digital I/O Ports on the 68HC11 Chip

This section describes how to configure and access the PORTA and PORTE digital ports in the 68HC11 chip on the QED Board.

As you work through the examples in the remaining sections of the chapter, you can use a voltmeter to verify that the outputs are behaving as you expect.  You can also connect the input signals through a 1 kOhm resistor to +5V or GND to verify that you can digitally read their values. (The 1 kOhm resistor is just a safety precaution to minimize the chance that you’ll “blow out” a port bit by mistakenly connecting an output bit to a supply voltage; even if you make this mistake, the resistor would limit the current to safe levels.)

Digital inputs and outputs are very useful in data acquisition, monitoring, instrumentation and control applications.  A low voltage (near 0 Volts) is established on a digital output pin when the processor writes a logical 0 to the corresponding bit in a data register associated with the digital output port.  A high voltage (near 5 Volts) is established on the digital output pin when the processor writes a 1 to a corresponding bit in the port’s data register.  This allows software to control external events and processes.  For example, an application program can use digital outputs to activate solenoids and turn switches and lights on and off, or to interface the QVGA Controller with a wide variety of digital accessories such as D/A converters, displays, etc.

A digital input allows the processor to monitor the logical state of an external voltage by reading a data register associated with the port.  External voltages near 0 Volts connected to a digital input cause the corresponding bit in the port’s data register to be read as a logical 0, and external voltages near 5 Volts connected to a digital input are read as a logical 1.  Application programs can use digital inputs to read switches and keypads or to interface to digital devices such as A/D converters and real-time clocks.

Using digital I/O is very easy:

   0.   Configure the direction of the digital I/O port.  This is accomplished by writing to a named data direction port (in the case of PORTA and PORTD) to set the directions of individual bits within a port, or by executing an initialization routine such as INIT.PIA.

   0.   To change the state of an output port, write to the port’s data register (whose address is left on the stack by simply stating the name of the port) using C!, SET.BITS, CLEAR.BITS, or other pre-defined operators.

   0.   To read the state of an input port, read the port’s data register with a C@ command; the result is left on the data stack.

The names of the data and direction registers and all required initialization routines are pre-defined in the QED-Forth kernel so you don’t have to hassle with hexadecimal register addresses in your code.  The following sections describe the available digital I/O ports and how to use them.

QED-Forth Provides Named Registers and Pre-coded Configuration Routines

The ports are addressed in common memory .  The 68HC11 ports are associated with data and direction registers in the processor’s 96 byte block of “Control and Status Registers” located at 8000H-805FH; Appendix B summarizes the contents of all of these registers.  The PIA ports are associated with data registers addressed at 8080H-8082H and a control register at address 8083H.

QED-Forth names the digital I/O ports, and when the name is executed the 32 bit extended address of the port’s data register is left on the stack.  This makes it easy to access the port; simply state the port’s name and use the standard byte fetch and store operations C@ and C! to read or write to the port.  Individual bits in the digital ports can also be modified with operators such as SET.BITS, CLEAR.BITS, TOGGLE.BITS, and CHANGE.BITS

The names of the digital I/O ports and the respective hexadecimal addresses left on the stack are as follows:



PORTA ( -- 8000\0 )

PORTD ( -- 8008\0 )

PORTE ( -- 800A\0 )

PPA   ( -- 8080\0 )

PPB   ( -- 8081\0 )

PPC   ( -- 8082\0 )

QED-Forth also makes it easy to configure the data direction (input or output) of the I/O ports.  The directions of the individual bits in PORTA and PORTD are controlled by direction registers which are named in QED-Forth.  The direction register names and the respective hexadecimal addresses left on the stack are as follows:



PORTA.DIRECTION   ( -- 8001\0 )

PORTD.DIRECTION   ( -- 8009\0 )

Writing a 1 to a bit in the data direction register sets the corresponding port bit to an output, and writing a 0 configures the bit as an input.  The commands C!, SET.BITS, or CLEAR.BITS can be used to modify the contents of the data direction registers.  Any combination of input and output bits may be specified for these ports.

The data direction of the PIA ports are set by the routine INIT.PIA which is described later in this chapter and in the glossary.

PORTE on the 68HC11 can be configured as an 8 channel 8 bit analog to digital converter by executing A/D8.ON, and it reverts to its default condition as an 8 channel digital input port after execution of A/D8.OFF.

Setting the Data Direction of PORTA and PORTD

Two named registers control the direction of the bits in PORTA and PORTD, respectively:



PORTA.DIRECTION

PORTD.DIRECTION

Writing a 1 to a bit in the direction register sets the corresponding port bit as an output, and writing a 0 to a bit in the direction register sets the corresponding port bit as an input.  A one-to-one correspondence exists between bits in the data direction register and its corresponding port.  These two ports are configurable on a bit-by-bit basis, so any combination of inputs and outputs can be specified.

For example, to set PORTA as all input, execute



00  PORTA.DIRECTION C!

To set the lower 4 bits of PORTA as input and the upper 4 bits as outputs, execute



HEX F0 PORTA.DIRECTION C!

To set the least significant bit of PORTA as an input while leaving the direction of all other bits unchanged, execute



01 PORTA.DIRECTION CLEAR.BITS

which clears the least significant bit in PORTA.DIRECTION to 0.



The direction of PORTD is controlled in the same way.  Recall that PORTD is a 6 bit port, and the two least significant bits are used by the primary serial channel.  This leaves the four bits PD2 through PD5 available for digital I/O if they are not used for the SPI.  For example, to set the four available bits PD2 through PD5 to all outputs, execute



HEX 3C PORTD.DIRECTION C!

The command



HEX FF PORTD.DIRECTION C!

has the exact same effect; the two least significant bits in PORTD are not affected by the PORTD.DIRECTION register, and the two most significant bits in PORTD do not exist.

Configuring PORTE as a Digital Input Port

PORTE is always an input port.  After each reset and restart, it is configured as an 8 channel digital input port.  Executing



A/D8.ON

turns on the 8 bit analog converter and configures PORTE as an 8 channel 8 bit analog input port (see Chapter 6).  Executing



A/D8.OFF

turns off the 8 bit A/D and configures PORTE as an 8 channel digital input port.

(For experts and the curious:  A/D8.OFF turns the 8 bit analog converter off by clearing the A/D power up bit named ADPU in the OPTION register; A/D8.ON sets the ADPU  bit; see MC68HC11F1 Technical Data Manual, p.6-4.)

For Experts: Fast Port Accesses

The following comments may help those who need maximum speed when accessing a port from within a Forth definition.

Because all of the named digital I/O ports are located in common memory, the fast page-less operator (C@) can be used to access the ports.  For example, the command



PORTE DROP (C@)   ( -- byte )

returns the same result as the command PORTE C@(C@) executes more rapidly than C@ because it does not change pages during the read operation.  But this time savings is mostly offset by having PORTE place the full extended address including page on the data stack at runtime, and then calling DROP to remove the page from the stack.  A more efficient method is to instruct the compiler to place only the 16 bit address on the stack at runtime, and then call (C@) to read the contents.  The following definition shows how this can be accomplished:



: READ.PORTE   ( -- )

   [ PORTE DROP ] LITERAL (C@)            \ this is a very fast fetch

   CR .” The contents of PORTE = “ .      \ display the result

;

The [ is an immediate word that invokes the execution mode.  PORTE DROP places the 16 bit address of the port on the data stack, and  ] re-enters the compilation mode.  LITERAL removes the 16 bit address of the port from the data stack and compiles it as a literal that will be placed on the stack at runtime so that (C@) may fetch its contents.  The rest of the definition prints the result.  This same technique may be used to read, modify, or write to any location in common memory.  A wide variety of fast page-less operators are available in the kernel, including (@), (!), (F@), (F!), (SET.BITS), (CLEAR.BITS), (TOGGLE.BITS), and (CHANGE.BITS).

Of course, the fastest way to access the contents of a port in common memory is to use assembly code.  The following routine leaves the contents of PORTE on the data stack:



CODE FETCH.PORTE.CONTENTS ( -- byte )

   PORTE DROP EXT LDAB \ B gets contents of portE

   CLRA \ zero upper byte of double accumulator

   DEY DEY \ make room on data stack

   0 IND,Y STD \ put result on data stack

   RTS

END.CODE

Because all of the named port addresses are located in the common memory, it is safe to DROP the page and use an assembly coded “load” operation such as LDAB to fetch the contents of the port.  Note that when assembly coding accesses to locations that are not in common memory, it is best to call the pre-coded memory access routines in the QED-Forth kernel (such as C@) which properly handle the page changes.

Port Initialization

The PORTA bits PA0 through PA7 are configured as inputs after a reset or restart, unless the serial2 port is specified as the default startup port (see the glossary entry for SERIAL2.AT.STARTUP).  If the secondary serial port is automatically initialized at startup, then PA4 is initialized as the serial output and PA3 is configured as the serial input.  The remaining PORTA pins are configured as digital inputs after the reset or restart.

PORTD bits PD2 through PD5 are configured as digital inputs after a reset or restart.  PORTE bits PE0 through PE7 are configured as digital inputs after a reset or restart; the default state of the 8 bit A/D converter is OFF.

Summary of Port Access

This chapter describes how to configure and access the 68HC11 digital I/O ports A, D and E and the PIA ports PPA, PPB, and PPC.  To use the digital I/O ports, follow these three simple steps.

   0.   Configure the direction of the digital I/O port.

      To configure PORTA, write to the PORTA.DIRECTION register using C! or a bit manipulation routine such as SET.BITS or CLEAR.BITS.  Writing a 1 to a bit position in PORTA.DIRECTION configures the corresponding port bit as an output, and writing a 0 to a bit position configures the corresponding bit as an input.  PORTA is configurable on a bit-by-bit basis.

      To configure PORTD, write to the PORTD.DIRECTION register.  PORTD is a 6 bit port, and the two least significant bits are used by the primary serial channel.  This leaves the four bits PD2 through PD5 available for digital I/O if they are not used for the SPI.  The available PORTD pins are configurable on a bit-by-bit basis.

      To configure PORTE for analog input, execute A/D8.ON.  To configure PORTE for digital input, execute A/D8.OFF. PORTE is configured as a digital input after a reset or restart.

      To configure the PIA, place two flags on the stack and execute INIT.PIA.  The first flag specifies the direction of PPA, and the second flag (top flag on the stack) specifies the direction of the upper nibble of PPC.  A true flag specifies output and a FALSE flag specifies input.  INIT.PIA configures PPB as an output and lower PPC as an input to ensure compatibility with the keypad/display drivers.

   0.   To change the state of an output port, write to the port’s data register (whose address is left on the stack by simply stating the name of the port) using C!, SET.BITS, CLEAR.BITS, or other pre-defined operators.

   0.   To read the state of an input port, read the port’s data register with a C@ command; the result is left on the data stack.

PORTA

PORTA is configurable as input or output on a bit-by-bit basis. To configure PORTA, use an assignment statement to write to the DDRA (Data Direction Register A) register.  DDRA and all 68HC11 register names are defined in the QEDREGS.H file in the \FABIUS\INCLUDE\MOSAIC directory.  Writing a 1 to a bit position in DDRA configures the corresponding port bit as an output, and writing a 0 to a bit position configures the corresponding bit as an input. For example, the following C statement configures PORTA as all outputs:



DDRA = 0xFF;

To configure PORTA as all inputs, use the statement:



DDRA = 0x00;

If we want to configure bits 0-6 as inputs, and bit 7 as output, we can execute:



DDRA = 0x80;

To change the state of an output bit on PORTA of the 68HC11 chip, use an assignment statement with PORTA on the left hand side to write to the port’s data register named PORTA.  For example, if PORTA is configured as all outputs, the following C statement sets all PORTA bits high:



PORTA = 0xFF;

To read the state of PORTA, use an assignment statement with PORTA on the right hand side to read the port’s data register. For example, the following code fragment reads PORTA and places the results in the variable named latest_porta_state:



static unsigned char latest_porta_state;

latest_porta_state = PORTA;

PORTE

PORTE (named in the QEDREGS.H file) is an 8 bit analog or digital input port.  PORTE is configured as a digital input after a reset or restart, and is read in the same way that PORTA is read: simply use it as the right hand side of an assignment statement.  For example, to read the digital state of PORTE, your program could execute the statements:



static unsigned char latest_porte_state;

latest_porte_state= PORTE;

To configure PORTE for analog input, use the function:



AD8On()

To turn off the 8 bit A/D and revert to a digital input port, use:



AD8Off()

(For experts and the curious:  AD8Off() turns the 8 bit analog converter off by clearing the A/D power up bit named ADPU in the OPTION register; AD8On() sets the ADPU bit.)

Using the PIA

This section describes how to configure and access the available I/O ports of the Peripheral Interface Adapter (PIA) on the QED Board.

PIA Initialization

The QED-Forth word



INIT.PIA ( flag1\flag2 -- | flag1 = ppa.output?, flag2 = upper.ppc.output?)

writes to the peripheral interface adapter (PIA) configuration register to set the data direction for PPA and the upper 4 bits of PPC.  If flag1 is true, INIT.PIA configures PPA as output, and if flag 1 is false, it configures PPA as input.  Likewise, if flag2 is true, INIT.PIA configures upper PPC as output, and if flag 2 is false, it configures upper PPC as input.  INIT.PIA sets the direction of PPB as output and lower PPC as input to ensure compatibility with the built-in keypad and display interfaces.  It clears bit 6 of PPB and sets bit 7 of PPB high so that the display.enable and 12 bit A/D chip select signals are inactive.  If the specified input/output configuration of the PIA is the same as the prior configuration, INIT.PIA does not modify the PIA configuration register, and thus does not change the state of any output pins in PPA or upper PPC.  If the specified PIA configuration is different than the prior configuration, INIT.PIA writes to the PIA’s configuration register and this automatically zeros any outputs in PPA or upper PPC.  Consult the PIA data sheet in Appendix C for details of the PIA operation.

The function



void InitPIA( int ppa_output_flag, int upper_ppc_output_flag)

writes to the PIA configuration register to set the data direction for PPA and the upper 4 bits of PPC.  If ppa_output_flag is true (non-zero), InitPIA() configures PPA as output, and if ppa_output_flag is false (zero), it configures PPA as input.  Likewise, if upper_ppc_output_flag is true, InitPIA() configures the upper four bits of PPC as output, and if upper_ppc_output_flag is false, it configures upper PPC as input.  InitPIA() sets the direction of PPB as output and lower PPC as input to ensure compatibility with the built-in keypad and high current driver interfaces . It clears bits 5, 6 and 7 of PPB which control high current driver outputs HC1, HC2, and HC3.

Warning!

There may be a short transient ON condition on the three high current outputs during power-up and reset.  The state of the PIA chip can not be controlled when it is initially turned on or reset.  A consequence of this is that in the interval of time between power-up and the operating system’s initialization of the output to an OFF condition, there may be a short transient ON.  You may need to take appropriate precautions in critical applications.

Additionally, if the specified PIA configuration is different than the prior configuration, INIT.PIAInitPIA() writes to the PIA’s configuration register and this automatically zeros any outputs in PPA or upper PPC, even if the direction of PPA or PPC was not changed!

If the specified input/output configuration of the PIA is the same as the prior configuration, INIT.PIAInitPIA() does not modify the PIA configuration register, and thus does not change the state of any output pins in PPA or upper PPC.  But, if the specified PIA configuration is different than the prior configuration, INIT.PIAInitPIA() writes to the PIA’s configuration register and this automatically zeros any outputs in PPA or upper PPC, even if the direction of PPA or PPC was not changed!  Consequently, INIT.PIAInitPIA() may disrupt in-progress operations involving the 12 bit A/D, keypad, or display.  INIT.PIA is called by INIT.A/D12&DAC, INIT.DISPLAY, and INIT.RS485Consult the PIA data sheet for details of the PIA operation.

When designing your application, the safest course is to perform all required initializations in an autostart routine as soon as the application program begins.  This avoids the problem of a late initialization that disturbs an in-progress I/O operation.

Upon each reset or restart, the PIA is configured as follows:



Port

Direction

PPA

input

PPB

output

lower PPC

input

upper PPC

input

Accessing PIA Ports PPA, PPB and PPC

The PIA (ports PPA, PPB, and PPC) uses as special set of routines to input or output values. These routines employ clock stretching to slow down the access of the on-board PIA to ensure that its timing criteria are met.



For example, to set all the bits of PPA to zero you would execute,

   0   PPA PIA.C!

The PIA.C! routine performs clock stretching (in other words, inserts wait states) during the access to PPA to guarantee that the timing conditions of the PIA are met.  It also disables interrupts for 27 cycles (less than 7 microseconds) during the memory access.

Similarly, PIA port bits can be read, set, cleared, toggled, and changed using the routines PIA.C@, PIA.SET.BITS, PIA.CLEAR.BITS, PIA.TOGGLE.BITS, and PIA.CHANGE.BITS, respectively.  Full descriptions for these routines are in the attached Glossary.

Because the timing of the PIA chip are slightly too slow for simple assignment-statement accesses to be “guaranteed by design” at a 16 MHz clock speed, a set of access functions has been defined that inserts a wait state while the PIA is being accessed.  This guarantees reliable performance over all device variations and temperature extremes.  To access the ports of the PIA (Peripheral Interface Adapter) chip, use the following functions defined in the PIA.H file and described in the Control-C Glossary:



void  PIAStore( uchar c, xaddr address )

uchar PIAFetch( xaddr address )

void  PIAChangeBits( uchar data, uchar mask, xaddr address )

void  PIAClearBits( uchar mask, xaddr address )

void  PIASetBits( uchar mask, xaddr address )

void  PIAToggleBits( uchar mask, xaddr address )

The three PIA port addresses are also defined as macros in the PIA.H file:



#define PPA_ADDRESS  ((xaddr) 0x8080)

#define PPB_ADDRESS  ((xaddr) 0x8081)

#define PPC_ADDRESS  ((xaddr) 0x8082)

where “xaddr” is a 32-bit extended address type specifier defined in the TYPES.H file.

These functions are easy to use, as illustrated by the following brief examples.  If your program has called InitPIA() to configure PPA as an output port, it can store the value 0x55 to the port by executing the C statement:



PIAStore(0x55, PPA_ADDRESS);

You can set the least significant bit in PPA by calling:



PIASetBits(0x01, PPA_ADDRESS);

where 0x01 is a mask; the 1’s in the mask specify which bits are to be set.

Your program can invert the state of the lower 4 output bits in PPA using the statement:



PIAToggleBits(0x0F, PPA_ADDRESS);

Again, 0x0F is a mask; the 1’s in the mask specify which bits are to be toggled, and the 0’s in the mask specify bits that are to be left unchanged.

If you’ve configured upper PPC as an input port, you can read its value with the statements:



static unsigned char  nibble_contents;

nibble_contents = PIAFetch(PPC_ADDRESS);

The upper 4 bits of nibble_contents will then contain the upper PPC input values.

Characteristics of the PIA’s I/O Ports

The 82C55A peripheral interface adapter (PIA) chip is the industry standard part for providing digital I/O ports.  This brief summary is intended to clarify some of the features of this chip.

The PIA is configured by writing to a control register at address 8083H.  The pre-defined routine INIT.PIAInitPIA() described earlier writes to this register.  It configures the PIA for simple digital I/O (“mode 0”) and sets the data direction of ports PPA and upper PPC according to user-supplied flags.  INIT.PIAInitPIA() configures PPB as an output and the lower half of PPC as an input.

Whenever the PIA is configured by writing to the control register, all outputs are set to the logic low state.  This is true whether or not the new configuration is different from the prior configuration.  The INIT.PIAInitPIA() routine tries to minimize the impact of this (often undesirable) “feature” by checking the control register before writing to it.  If the PIA configuration requested by the programmer is the same as the existing configuration, the PIA’s control register is not modified.  In general, it is best to use a static configuration for the PIA; dynamically changing the direction of PIA ports while the application is running can cause troublesome glitches on the PIA output pins.

The PIA has another unusual “feature” called “bus hold circuitry”.  The PIA tries to maintain specified logic levels on pins that are configured as inputs (rather than the standard approach of leaving the input pins in a “floating” high impedance state).  After a reset or change in configuration, the PIA holds all inputs high by sourcing between 50 and 400 microamps into the external load attached to the input pin.  If your design requires that the inputs settle to a voltage near ground, you will need to pull the pins low with external pull-down resistors that connect each input pin to ground.  The resistors should have a value less than 1 K-ohm; the manufacturer suggests that the pull-down should be 640 ohms to ensure a logical 0 under worst-case conditions.  Port PPA also has bus hold circuitry that can hold an input in the low condition.  If your design requires that PPA inputs be held at a logical high state, install external pull-up resistors of less than 3 K-ohms from the PPA input pins to the +5 Volt supply.

PIA output pins have good current drive capabilities.  The data sheet states that the chip can maintain an output high voltage of at least 3.0 Volts while sourcing up to 2.5 mA.  The manufacturer’s technical support staff claims that the typical performance is much better; they say that a typical chip can maintain 3.0 Volts or higher while sourcing up to 20 mA.  In the worst case the PIA outputs can sink up to 2 mA while maintaining the output voltage below 0.4 Volts.  There is no internal current limiting on the outputs, so your custom circuitry should include current-limiting resistors if significant current will be required from the output pins.

Using the High Current Drivers

Four N-channel MOSFET high current drivers are available at the Supplementary I/O connector.  Each driver can sink up to 150 mA continuously, or up to 1 amp on an intermittent basis at voltages as great as 60 V.  Onboard snubber diodes suppress inductive kickback, so the drivers can be used to control solenoids, motors, and other inductive loads.

Figure 8‑1 shows how to connect a DC load (a DC motor is shown) to the MOSFETs.

Figure 8‑1    Connecting a DC load (for example, a DC motor) to the high current drivers using onboard power (left) and using external power (right).

HC0 is controlled by a PAL signal and HC1 - HC3 are controlled by the PIA port bits PPB5 - PPB7 respectively.  NOTE: Upon power-up and reset, the high current MOSFETs, HC1 - HC3, may momentarily sink current until the QED-Forth startup software initializes them.  The PAL-controlled HC0 output does not exhibit this transient turn-on behavior at startup.

Two simple functions control these four high current drivers:



void  ClearHighCurrent( uchar mask )SET.HIGH.CURRENT

void  SetHighCurrent( uchar mask )CLEAR.HIGH.CURRENT

SET.HIGH.CURRENT SetHighCurrent()  accepts a 4-bit mask and turns on the drivers that correspond to "1"s in the mask.  CLEAR.HIGH.CURRENT ClearHighCurrent() accepts a 4-bit mask and turns off the drivers that correspond to "1"s in the mask.  Note that "turning on" a driver allows it to sink current, thereby pulling the voltage at the output pin towards ground.  "Turning off" a driver prevents it from sinking current. For example, to turn on all four high current drivers, execute



      SetHighCurrent( 0x0F )



      HEX   0F SET.HIGH.CURRENT

Then, if you execute



ClearHighCurrent( 0x01 )



01  CLEAR.HIGH.CURRENT

you will turn off driver number 0 while leaving the state of the other three drivers unchanged.



You can verify the operation of the high current outputs by connecting a pullup resistor (say, 1 kOhm) from the output to +5V and measuring the output voltage with a voltmeter.  Note that the output voltage goes LOW when the output is ON (sinking current to ground), and the voltage goes HIGH when the output is OFF (no current flowing in the load resistor).

Using Uninterruptable Operators

The Importance of Uninterruptable Operators

Sometimes it is necessary to set, clear, toggle, or change one or more bits in a port while leaving other bits unaffected.  QED-Forth provides convenient read/modify/write routines called SET.BITS, CLEAR.BITS, TOGGLE.BITS, and CHANGE.BITS to accomplish these functions.  The corresponding fast page-less operators named (SET.BITS), (CLEAR.BITS), (TOGGLE.BITS), and (CHANGE.BITS) can also be used to modify the contents of addresses in common memory.  The glossary entries provide detailed descriptions of these operations.

For example, if upper PPC has been configured as an output using INIT.PIA, the top 4 bits in PPC can be cleared to zeros by executing



HEX F0 PPC CLEAR.BITS

F0 is a bit mask with the top 4 bits equal to ones; this tells CLEAR.BITS that only the top 4 bits should be cleared. The bottom 4 bits of PPC are unaffected.

SET.BITS, CLEAR.BITS, TOGGLE.BITS, and CHANGE.BITS (and the corresponding page-less operators) globally disable interrupts just before reading the memory contents and restore the prior state of the interrupt flag (enabled or disabled) after writing to the specified address.  This makes these routines robust with respect to interrupts and timesliced multitasking when two or more concurrently executing routines are modifying bits in the same memory location.

The following scenario illustrates the importance of these uninterruptable operators when more than one task or interrupt routine is writing to a memory location.  Let’s assume that two different tasks are controlling the bits of the upper nibble of PPC.  Assume that TASK1 is controlling the state of bit 4 in PPC (perhaps to set the direction of the RS485 transceiver), and TASK2 controls bit 7 in PPC.  Let’s assume that bit 4 is low when TASK2 tries to execute the following sequence:



HEX

PPC C@  80 OR

PPC C!

TASK2 is merely trying to set the top bit in PPC to 1, but this sequence of commands may have unintended consequences.  Assume that the timeslicer interrupt is serviced just after the OR instruction and transfers control to TASK1TASK1 may change the state of bit 4 to a 1.  When control is then transferred back to TASK2, the remaining command PPC C! is executed.  Unfortunately, this C! command erroneously sets bit 4 back to the low state!  TASK2 was interrupted after it read the state of PPC but before it had a chance to write the new contents, so it undoes the change that TASK1 made in the state of PPC bit 4.

The uninterruptable read/modify/write routines avoid this problem by disabling interrupts for ten to sixteen cycles (5 to 8 microseconds at an 8 MHz crystal speed).  This prevents the corruption of the contents when different tasks or interrupts share access to a single location.

Similar problems can arise when one task writes to a floating point or other 4-byte variable, and a second task needs to read the saved value.  The data that is read may be invalid if the read or the write is interrupted between the time of the writing/reading of the first 16 bits and the writing/reading of the second 16 bits.  For this reason a set of uninterruptable operators denoted by the | (“bar”) character are in the kernel.  These are |2@|, |F@|, |X@|, |2!|, |F!|, and |X!|.  Consult the “Multitasking” chapter in the Software Manual for a more detailed discussion of this topic.

Care must be taken when performing “read/modify/write” operations in applications that use interrupts or multitasking.  Operations such as setting or clearing individual bits in a byte while leaving other bits unchanged are called “read/modify/write” operations because they involve reading the port, modifying the read contents, and writing the result back to the port.  Unpredictable results can occur if more than one interrupt service routine or task tries to access a single port or memory location at the same time using a read/modify/write sequence.  The simplest solution to this problem is to access the memory location or port using an “uninterruptable” read/modify/write operator.

The following scenario illustrates the importance of uninterruptable operators when more than one task or interrupt routine is writing to a memory location.  Let’s assume that two different tasks are controlling the bits of PORTA.  Assume that TASK1 is controlling the state of bit 4, and TASK2 controls bit 7.  Let’s assume that bit 4 is low when TASK2 tries to execute the following code:



static unsigned char mask = 0x80;

PORTA |= mask;

TASK2 is merely trying to set the top bit in PORTA to 1, but this statement may have unintended consequences.  The compiler generates code that reads the contents of PORTA, performs a bitwise OR with the contents of mask, and stores the result back into PORTA.  Assume that the timeslicer interrupt is serviced just after the OR instruction and transfers control to TASK1.  TASK1 may change the state of bit 4 to a 1.  When control is then transferred back to TASK2, the final store to PORTA is executed.  Unfortunately, this store command erroneously sets bit 4 back to the low state!  TASK2 was interrupted after it read the state of PORTA but before it had a chance to write the new contents, so it undoes the change that TASK1 made in the state of PORTA bit 4!  This can indeed cause problems in an application program.

Pre-coded Read/Modify/Write Functions

The pre-coded PIA and High Current Driver read/modify/write functions described earlier in this chapter avoid this problem by disabling interrupts for ten to sixteen cycles (2.5 to 4 microseconds at a 16 MHz crystal speed).  This prevents the corruption of the contents when different tasks or interrupts share access to a single location. The following functions are uninterruptable:



void  PIAChangeBits( uchar data, uchar mask, xaddr address )

void  PIAClearBits( uchar mask, xaddr address )

void  PIASetBits( uchar mask, xaddr address )

void  PIAToggleBits( uchar mask, xaddr address )

void  ClearHighCurrent( uchar mask )

void  SetHighCurrent( uchar mask )

Additional uninterruptable operators are declared in the XMEM.H header file in the \MOSAIC\FABIUS\INCLUDE\MOSAIC directory; these routines are described in detail in the Control-C Glossary.

Create Your Own Uninterruptable Functions

It is easy to create your own uninterruptable functions using the _protect keyword.  For example, the following uninterruptable function sets specified bits in a port or memory byte:



void _protect  SetBitsUninterrupted( uchar mask, char* address )

{  *address |= mask;

}

In response to the _protect keyword, the compiler ensures that interrupts are temporarily disabled while SetBitsUninterrupted() is executing, and that the global interrupt mask (the I bit in the condition code register) is restored to its prior state after the function terminates.

Simple stores to and fetches from 1-byte or 2-byte memory locations are intrinsically uninterruptable because they are implemented with single assembly-language opcodes.  However, the 68HC11 processor does not have a single opcode that can access a 32 bit memory location.  Thus, problems can arise when one task writes to a floating point or long variable, and a second task needs to read the saved value.  The data that is read may be invalid if the read or the write is interrupted between the time of the writing/reading of the first 16 bits and the writing/reading of the second 16 bits.  In these cases uninterruptable operators should be used.  An example is presented by the functions named:



PeekFloatUninterrupted()

PokeFloatUninterrupted()

which are defined using the _protect keyword in the TURNKEY.C program in the \MOSAIC\DEMOS_AND_DRIVERS\MISC\C EXAMPLES directory; this program is discussed in detail later in this book.

Connecting Hardware to the Digital I/O Lines

You may connect to the digital I/O lines by connecting IDC ribbon cable sockets to heaer H3 on the QED Board (for port PPB, the lower nibble of PPC, and high current drivers), or to header H2 on the QVGA Board (for processor port PA, PI A port PPA, and the upper nibble of PPC).  In either case, you should connect only to the I/O signals on the connector, and not to the system control lines, data or address lines, clock, or SPI lines.

Do Not Connect to System Control Signals

When connecting to the Digital I/O Connector (H2 on the QVGA Board) with a ribbon cable, notch out cable wires 11 through 24.  Even short pieces of wire connected to some of these lines may cause intermittent operation of the touchscreen or processor.

When connecting to the Supplemental I/O Connector (H3 on the QED Board) with a ribbon cable, only connect the wires you need, and do not connect to the data bus lines or system control lines.

Electrical Characteristics of the 68HC11’s I/O Ports

On the QVGA Controller the processor’s ports A and D are available for you to connect to external devices.  You can use them to directly drive LEDs, relays, transistors, opto-isolators or other digital logic devices.  But please be careful -- whenever these outputs are connected to external devices you must stay within the voltage and current capabilities of the output pins.  Because the MC68HC11 reference manuals don’t specify the electrical capability of these ports very well we provide some additional information here.

The electrical characteristics of the 68HC11F1’s digital I/O signals are specified in detail in section 13.4 of the MC68HC11F1 Technical Data Manual.  This table lists the “DC Electrical Characteristics” of the processor.

Pins on the 68HC11 configured as digital inputs report a logical “high” if the input voltage is greater than 0.7 times the supply voltage, or 3.5 Volts.  They report a logical “low” if the input voltage is less than 0.2 times the supply voltage, or 1.0 Volt.  Input voltages between 1.0 and 3.5 Volts may be read as either high or low.

Pins on the 68HC11 configured as digital outputs in the “high” state can maintain the output voltage within 0.8 Volts of the positive supply if 0.8 mA or less is being drawn from the pin.  If less than 10 microamps is being drawn, the output high voltage is within 0.1 Volt of the positive supply.  In the low state, the digital outputs can keep the voltage below 0.4 Volts while sinking up to 1.6 mA of current.  Load circuitry that requires significant current to be sourced or sunk by the digital output should include external resistors to ensure that the absolute maximum rating of 25 mA per output pin is never exceeded.

Protecting the Input and Output Pins

These output pins are very useful because they can directly drive a wide range of devices.  Nevertheless, any circuitry connected to the processor should take care to:

  Prevent excessive voltage levels at the pin; and,

  Prevent excessively great currents.

We’ll address each of these concerns in turn.

Preventing Excessive Voltages

Excessive voltages are prevented by ensuring that voltages of less than a diode drop below VSS (-0.6 V) or greater than a diode drop above VDD (VDD+0.6 V ) are never applied to the processor. For some applications, particularly when driving inductive loads such as relays, you may need to provide Schottkey diode clamps between the pin and VDD and between the pin and ground.  All pins on the processor have inherent diode clamps to the processor’s ground voltage, VSS, but it is best not to rely on these; if there is the possibility of the output pin being driven to a negative voltage level it is better to prevent excessive power dissipation in the processor package by externally clamping the voltage to ground (VSS) with a Schottkey diode.  Processor ports A and D also have inherent diode clamps to the chip’s +5V supply voltage, VDD, but it is likewise better not to rely on these; instead external Schottkey clamps to VDD should be used.

Preventing Excessive Currents

The current into or out of any pin on the MC68HC11 should also be limited to prevent damage.  The specified maximum current is 25 mA into or out of any one pin at a time, although these pins can typically withstand transients of more than 100 mA at room temperature.  In driving more than one pin at a time it is necessary only to stay within the processor’s maximum power dissipation.  Unfortunately, Motorola doesn’t specify what this maximum is, but we recommend that you don’t exceed a total of 100 mW for all processor I/O pins combined.  The chip’s total power dissipation is the sum of its internal power (which varies from device to device so much that it can only be determined by actually measuring it, but which is specified at less than 150 mW) and the power associated with the I/O pins.  Pin currents must be limited using external resistors.

Output Pin V-I Characteristics

The output pins of the MC68HC11 are similar in electrical characteristics to the SN54/74HC digital logic family.  They can source or sink up to 25 mA and are guaranteed to source 0.8 mA while providing a valid logic high and to sink 1.6 mA at a valid logic low, although they generally do much better.  A valid logic high level is between VOH = VDD and VOH = VDD - 0.8 V, and a valid low level is between VOL =VSS = 0 V and VOL =VSS + 0.4 V.  As the output is loaded, the VOL and VOH levels rise or fall. It is often useful to know just how much to expect the VOL and VOH levels to degrade with current.  For currents of less than 10 mA the voltage change is linear with current; that is, it can be modeled as a voltage source of either zero or five volts and an equivalent series resistance of 40 ohms. At greater output currents the resistance increases until at the greatest specified current for any one pin, 25 ma., the equivalent resistance is 60 ohms.  At this current the voltage degradation of the VOL or VOH is 1.5 volts.  Figure 8‑2 and Figure 8‑3  illustrate this variation.

These figures can be used to choose component values for particular circuits.  For example if we wish to use a pin of Port A or D to drive a light-emitting diode we would place the LED in series with a resistor and connect them between an output pin and ground.  The resistor limits the current, to the LED.  From the LED data sheet we note that its forward voltage at a current of 10 mA is specified to be 2.2 V.  What should the resistor value be?  We calculate it as,

Eqn. 8‑1      R = (VOH - 2.2 V ) / 10 mA

Consulting the VOH vs I curve for the output pin we find that at 10 mA VOH = 4.4 V.  We therefore need a resistance of 220 ohms.

Figure 8‑2    Degradation of the Port A or Port D output high voltage with current.  The maximum current allowed for continuous operation is 25 ma.

Figure 8‑3    Degradation of the Port A or Port D output low voltage with current.  The maximum current allowed for continuous operation is 25 ma.



From Old Hardware Manual



****************



Accessing Digital I/O Ports

The three PIA ports are named in QED-Forth as PPA, PPB, and PPC (meaning peripheral port A, B, and C respectively).  The available digital ports on the 68HC11 processor are also named; they are PORTA, PORTD, and PORTE.  PORTA is a bitwise-configurable I/O port with associated counting and timing functions; it also supports the serial2 software UART on pins PA3 (input) and PA4 (output). PORTD pins PD2 to PD5 can be used as the serial peripheral interface (SPI) or as bitwise-configurable I/O.  PORTE can be used as an octal 8 bit A/D, or as 8 bits of digital input if the A/D converter is turned off.

Digital ports with some or all of their bits configured as outputs can be written to using the standard C! (pronounced “C-store”) operator.  For example, if you first set PPA as an output by executing



TRUE FALSE INIT.PIA

then the command



HEX   FF PPA C!

stores the value 0xFF into PPA in the peripheral interface adapter and sets all of its outputs high. Try measuring the PPA outputs with a voltmeter; the output voltage should be approximately 5 Volts.

Digital ports with some or all of their bits configured as inputs can be read using the standard C@ (pronounced “C-fetch”) operator.  For example, if PORTE is left in its default state configured as a digital (as opposed to analog) input port, the command

PORTE C@    ( -- byte )

leaves the contents of the PORTE data register on the stack.  The resulting byte left on the stack reports a 1 in the bit position corresponding to each pin of PORTE that senses a voltage higher than 3.5 Volts.  Likewise, the byte will contain a 0 in the bit positions corresponding to all pins with a voltage lower than 1.0 Volts.  Try connecting some PPA output pins to the PORTE inputs by wiring the appropriate pins on the 40 pin Digital I/O connector together (always be sure that you’ve identified the correct pins!)  Now you can write to PPA and verify the results by reading PORTE.

Alternate Uses of the Digital I/O Ports

Many of these port signals have alternative uses as summarized in Figure 2.1.  The 68HC11’s I/O ports can serve these multiple functions:

PORTA may be used as bit-configurable digital input/output.  The data direction (input or output) of PORTA is determined by writing to the PORTA.DIRECTION register as described below.  If any bits in PORTA are not being used for digital I/O, they may be used to implement a variety of counting and timing functions including input captures, output compares, and pulse accumulation as described in Chapter 4.  In addition, QED-Forth provides an optional software UART that supports a secondary RS232 serial port (called Serial2) using pins 3 and 4 of PORTA (see Chapter 11).

PORTD is a 6 bit port.  Bits 2-5 of may be used as bit-configurable digital I/O.  The data direction (input or output) of PORTD is determined by writing to the PORTD.DIRECTION register as described below.  The two least significant bits of PORTD (PD0 and PD1) are the receive and transmit lines for the serial communications interface.  Changing the data direction bits for these two signals has no effect unless you have disabled serial communications.

If PD2 through PD5 are not being used for general purpose digital I/O they may implement the SPI (serial peripheral interface).  The SPI is a fast synchronous serial link which is used to communicate with the optional onboard 12 bit analog to digital converter (A/D12) and 8 bit digital to analog converter (DAC).  The SPI is turned on by executing INIT.SPI and is turned off by executing SPI.OFF.  The SPI is initially off after a reset or restart; see Chapter 5 for a detailed description of this versatile serial link.

PORTE provides 8 input lines.  They may be used as the analog inputs to the 68HC11’s built-in 8 bit A/D converter, or they may be used as general purpose digital inputs if the 8 bit A/D converter is turned off.  The command A/D8.ON turns the 8 bit A/D on, and the command A/D8.OFF turns it off.  The 8 bit A/D is initially off after a reset or restart; see Chapter 6 for more details.

The PIA’s three ports serve the following functions:

PPA has no alternate functions and is always available as a digital input or output port.

The upper 4 bits of PPC are available as digital input or output if RS485 communications are not being used.  If RS485 communications are used, bit 4 of PPC (that is, the lowest bit in the upper nibble of PPC) controls the direction of the RS485 transceiver, and the upper half of PPC must be configured as an output (see Chapter 11 and the glossary entry for INIT.RS485).

The top bit (bit 7) of PPB is used as the chip select signal of the 12 bit A/D converter.



Digital I/O Connections

Figure 2.2 summarizes the pinouts of the 40 pin Digital I/O connector and the 40 pin Analog I/O connector on the QED Board.  The signals of PORTA, PORTD, PPA, and the upper nibble of PPC are available on the Digtial I/O connector. The PORTE signals which can be configured as either analog or digital inputs are available on the Analog I/O connector.





The 4 PORTD signals are labeled

PD2/MISO                                                                                                                                                                                           PD3/MOSI                                                                                                                                                                                           PD4/SCK                                                                                                                                                                                           PD5//SS

The first part of each signal name conveys the position in PORTD, and the second part is the signal name of the shared SPI (serial peripheral interface) function.  These signals are brought out to pins 11 through 14 on the 40 pin Digital I/O connector (see Figure 2.2).  The SPI is discussed in detail in Chapter 5.



The 8 PORTE signals are labeled

PE0/AN0                                                                                                                                                                                           PE1/AN1                                                                                                                                                                                           PE2/AN2                                                                                                                                                                                           PE3/AN3

PE4/AN4                                                                                                                                                                                           PE5/AN5                                                                                                                                                                                           PE6/AN6                                                                                                                                                                                           PE7/AN7

The first part of the signal name indicates the position in PORTE, and the second part reflects each signal’s shared function as an 8 bit A/D input.  These signals are brought out to pins 3 through 10 on the 40 pin Analog I/O connector (see Figure 2.2). Chapter 6 provides more detail about the A/D converter.

The 8 PPA signals originating at the PIA are labeled

PPA0                                                                                                                                                                                           PPA1                                                                                                                                                                                           PPA2                                                                                                                                                                                           PPA3                                                                                                                                                                                           PPA4                                                                                                                                                                                           PPA5                                                                                                                                                                                           PPA6                                                                                                                                                                                           PPA7

These signals are brought out to pins 29 through 36 on the 40 pin Digital I/O connector (see Figure 2.2).  The 8 bit PPA port does not have any shared functions and is always available as general purpose digital input or output.

The upper 4 bits of PPC are labeled

PPC4/RS485.XMIT                                                                                                                                                                                           PPC5                                                                                                                                                                                           PPC6                                                                                                                                                                                           PPC7

and are brought out to pins 25 through 28 on the 40 pin Digital I/O connector (see Figure 2.2).  If RS485 serial communications are used, PPC4/RS485.XMIT controls the direction of the data transfer, and the upper half of PPC must be configured as an output (see the glossary entry for INIT.RS485).  If RS485 is not being used, upper PPC can be configured as input or output.

PPB and the lower nibble of PPC are used to implement the keypad/display interface, and are brought out to the 34 pin keypad/display connector.  The port bits are brought out in a “scrambled” order that facilitates direct connection of a keypad and display.

Programmable Timer and Pulse Accumulator

Introduction

This section describes how the programmable timer and pulse accumulator can be used to:

                                                                                                                                                                                                                                                                                                                                                                                      Implement clocks

                                                                                                                                                                                                                                                                                                                                                                                      Measure time intervals

                                                                                                                                                                                                                                                                                                                                                                                      Sense input signal transitions

                                                                                                                                                                                                                                                                                                                                                                                      Measure input signal pulse widths

                                                                                                                                                                                                                                                                                                                                                                                      Generate output pulse signals

                                                                                                                                                                                                                                                                                                                                                                                      Control stepper motors with synchronized output pulse signals

                                                                                                                                                                                                                                                                                                                                                                                      Count external events represented by input pulses

These feats are accomplished by the 68HC11F1’s programmable timer and pulse accumulator subsystem. Controlled by a set of hardware registers, the subsystem performs input captures, output compares, pulse accumulation, gated timing, and real-time interrupt generation.

A 16-bit free running counter is the heart of the programmable timer.  All input capture and output compare operations are referenced to its count.

An input capture saves the time at which a specified input signal transition occurs.  This allows accurate timing of external signals.  Interrupts may optionally be generated when the signal transitions occur.  Coded examples presented below show how to use input captures to sense input signal level changes and measure input pulse widths.

An output compare causes actions to occur when the count in a specified register matches the value of the free-running counter.  The output compare can change the state of an output pin at a programmable time, and can optionally generate an interrupt at the same time.  Coded examples illustrate their use in synthesizing accurate clocks, generating output pulse signals, and implementing time-controlled program execution.  In addition, a sample stepper motor control program that generates synchronized output signals is presented.

The 8-bit pulse accumulator increments a count every time a specified signal transition is detected.  An associated gated timer increments a count driven by an internal clock as long as an external gating input is active.  Optional interrupts can be generated when the 8-bit count overflows and when a pulse or gate-signal edge is detected.  Coded examples illustrate their utility for counting external events and measuring pulse widths.

The real-time interrupt generates an optional interrupt at programmable intervals to time events or to establish a time base.

All of these functions are controlled by registers located at addresses 8000H-805FH in common memory.  Each register’s name is highlighted in BOLD when it is first introduced.  The names, addresses, and contents of all of the registers are summarized in Appendix B.  The example code uses the REGISTER: routine defined in QED-Forth to assign a name and extended address to each relevant control register.

The 16-Bit Free-Running Counter

The heart of the programmable timer is a 16-bit free running counter (MC68HC11F1 Technical Data Manual, , p. 7.2).  The counter is accessible via a read-only timer count register named TCNT (M68HC11 Reference Manual,  p.10-5).  Its value is incremented continuously at a programmable rate.  The count progresses from 0 to 65,535 (FFFFH) and then overflows to 0 and continues counting.  The input capture and output compare functions use TCNT’s contents to record when an event has occurred, or to determine when a specified output event should be initiated.

The following code defines the TCNT register and shows that its contents are being continually updated:



HEX

800E REGISTER: TCNT  \ define the location of the timer count register

TCNT C@ .         \ Read the contents of the timer counter, and

TCNT C@ .         \ note that each time the result is different.

TCNT C@ .

The free-running counter’s resolution is programmed by two prescaler bits named PR0 and PR1 located in the timer interrupt mask register 2, TMSK2 (M68HC11 Reference Manual,  pp.10-7...10-10, MC68HC11F1 Technical Data Manual,  p.7-9).  Their settings determine whether the timer count register’s frequency is equal to the system (2 MHz E-clock) frequency divided by 1, 4, 8, or 16.  The following table summarizes the count resolutions and overflow ranges of the TCNT register for the four possible combinations of prescaler bits 0 and 1 (PR0 and PR1):

Table 8‑5                                                                                                                                                                                           Free-Running Counter Resolution and Range.

The bold entries highlight the default values.  QED-Forth initializes PR0 and PR1 to achieve a count resolution of 2 microseconds (us) and a time-until-overflow of 131.1 milliseconds (ms).  If the crystal frequency is 8 MHz, the default values are PR1 = 0 and PR0 = 1; if the crystal frequency is 16 MHz, the default values are PR1 = 1 and PR0 = 0.  (For experts and the curious: a flag at address FFC0 in the kernel PROM tells QED-Forth what crystal frequency the board was manufactured with).  The values of prescale bits 0 and 1 can be verified by executing the following commands:



HEX

8024 REGISTER: TMSK2 \ define a control register constant for TMSK2

TMSK2 C@             \ fetch the contents of TMSK2

3 AND                \ AND with 3 to isolate PR0 and PR1 bits

.                    \ print the result

These prescaler bits in TMSK2 may be changed only during the first 64 cycles of processor operation after a reset.  The QED-Forth word INSTALL.REGISTER.INITS allows you to specify the contents of TMSK2 that will take effect after every reset; see its glossary description for details.

The timer count register overflows to 0 when its count reaches 65,535 (FFFFH).  When an overflow occurs, a timer overflow flag is set.  The flag is named TOF and it is located in the timer interrupt flag register 2, TFLG2.  If the timer overflow interrupt is enabled by setting the TOI mask bit in the TMSK2 register, then an interrupt is triggered when the timer overflow flag is set  (M68HC11 Reference Manual,  pp.10-9...10-10, MC68HC11F1 Technical Data Manual,  p.7-9&10). Like most interrupt flags, the timer overflow flag is reset by writing a one to its location in the TFLG2 register (see Chapter 3 for a discussion of interrupts).

Polling the Timer Overflow Flag

We can define a routine that times an interval by polling the overflow flag.  Given the default settings of the timer prescaler bits 0 and 1, the timer overflow flag is set every 131.1 ms.  Thus it is possible to measure intervals of n*131.1 ms.  For example, the following code times an approximate 6 second interval:

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

HEX

8025 REGISTER: TFLG2          \ define timer interrupt flag register 2

80 CONSTANT TIMER.OVERFLOW.FLAG  \ define a mask to isolate the TOF bit

\ in the TFLG2 register



: POLL ( mask\xaddr -- | iterate until bits set in mask are set in xaddr )

   \ compares the specified mask to the value at xaddr until the bits set in

   \ mask are also set in xaddr.  This routine could be assembly coded

   \ for use in more time-critical applications.

   LOCALS{ x&addr &mask }

   BEGIN

      x&addr C@      \ fetch the contents of xaddr

      &mask AND      \ AND the contents with the given mask

      &mask =     \ the mask bits are set in xaddr if this is true

   UNTIL

   ;



DECIMAL           \ set number base to decimal

6.0 0.1312 F/ FIXX CONSTANT #OVERFLOWS.IN.6SECONDS

\ define constant that equals the number of timer overflows

\ {which occur every 0.1312 seconds} per 6 second interval



: TIME.6.SECONDS ( -- )

   \ times an approximate 6 second interval by counting timer overflows.

   TIMER.OVERFLOW.FLAG TFLG2 C!     \ reset the TOF flag

#OVERFLOWS.IN.6SECONDS 0      \ specify number of overflows

   DO

TIMER.OVERFLOW.FLAG TFLG2 POLL   \ poll for next overflow

      TIMER.OVERFLOW.FLAG TFLG2 C!     \ reset the TOF flag

   LOOP

   CR .” 6 seconds are up!”

   ;

TIME.6.SECONDS resets the timer overflow bit and then polls it, waiting for approximately 6 seconds to elapse.  This simple routine is for demonstration purposes only, and is admittedly not very accurate.  Another drawback is that polling unnecessarily ties up the CPU.  Interrupts offer an attractive alternative.

Interval Timing – An Illustration of Interrupt Processing

It is simple to have the 68HC11F1 service an interrupt whenever the timer count register overflows.  This increases the accuracy of timed delays, and also frees the CPU for concurrent processing.

When the timer count register overflows, the timer overflow interrupt flag, TOF, is set.  If the local timer overflow interrupt mask bit named TOI is set in the TMSK2 (timer mask 2) register, an interrupt is recognized every time the timer overflow flag is set by the processor (MC68HC11F1 Technical Data Manual, p.7-9).  When a timer overflow interrupt is serviced, it is the responsibility of the interrupt handler to reset the timer overflow flag.

The following example demonstrates how to write a 6.031 second interval timer using interrupts.  The numbered, bold face comments correspond to the four steps used to implement interrupts as described in Chapter 3.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

\ 1. Define constants representing registers related to the interrupt.

HEX               \ use hexadecimal base to specify addresses

8024 REGISTER: TMSK2 \ define a control register constant for TMSK2

8025 REGISTER: TFLG2       \ define the timer interrupt flag #2 register

80     CONSTANT TIMER.OVERFLOW.FLAG    \ define a mask to isolate the TOF bit

                        \ in the TFLG2 register

80 CONSTANT TIMER.OVERFLOW.INTERRUPT.MASK \ used to set the TOI bit in TMSK2

VARIABLE #TIMER.OVERFLOWS           \ keeps a running count of overflows.

DECIMAL \ set number base to decimal

6.0 0.1312 F/ FIXX    CONSTANT #OVERFLOWS.IN.6SECONDS

\ define an integer constant that equals the approximate number of timer

\ overflows {which occur every 0.1312 seconds} per 6 second interval



\ 2. Write an “interrupt handler” routine

\ Define the timer overflow interrupt handler which resets the timer overflow

\ flag.  If 6 seconds (= 46*131 ms) have elapsed, the routine BEEPs and resets

\ the #TIMER.OVERFLOWS variable; otherwise, it increments #TIMER.OVERFLOWS



: BEEP.EVERY.6.SECONDS ( -- )

   TIMER.OVERFLOW.FLAG TFLG2 C!     \ reset the TOF flag

   #TIMER.OVERFLOWS @ #OVERFLOWS.IN.6SECONDS

>=                      \ have 6 seconds elapsed?

   IF BEEP                 \ yes, so beep

      #TIMER.OVERFLOWS OFF       \ and reset the counter

   ELSE  1 #TIMER.OVERFLOWS +!         \ no, so increment the #overflows

   ENDIF

;



\ 3. Write an installation word for the interrupt handler

\ INSTALL.ALARM uses the QED-Forth word ATTACH to properly install

\ the timer overflow handler BEEP.EVERY.6.SECONDS.

: INSTALL.ALARM ( -- )

   CFA.FOR BEEP.EVERY.6.SECONDS  TIMER.OVERFLOW.ID   ATTACH

;



\ 4. Write words to enable and disable the interrupt.

\ ARM.ALARM enables the 6 second beeper by clearing the #TIMER.OVERFLOWS

\ variable, clearing the timer overflow flag bit TOF, locally enabling

\ the timer overflow interrupt by setting its TOI mask bit, and ensuring

\ that the I bit is clear so interrupts are globally enabled.

: ARM.ALARM ( -- )

   #TIMER.OVERFLOWS OFF          \ initialize the overflow counter to 0

   TIMER.OVERFLOW.FLAG TFLG2 C!           \ reset the TOF flag

TIMER.OVERFLOW.INTERRUPT.MASK TMSK2 SET.BITS \ set the TOI mask

ENABLE.INTERRUPTS          \ ensure that the I bit is clear

;



\ DISARM.ALARM disables the timer overflow interrupt by clearing the timer

\ overflow interrupt mask bit.  Note that the global interrupt mask bit I is not

\ used to disable the interrupt, as this would affect all maskable interrupts.

: DISARM.ALARM ( -- )

TIMER.OVERFLOW.INTERRUPT.MASK  TMSK2  CLEAR.BITS

;

After defining these words, install the timer overflow interrupt handler and activate it by typing:



INSTALL.ALARM

ARM.ALARM

Your QED Board will now beep by transmitting a bell character every 6.031 seconds.  To stop the beeping type:



DISARM.ALARM

Try fetching the contents of #TIMER.OVERFLOWS several times while the timer overflow interrupt is operating.  The value stored in the variable changes every 131.1 ms.  This is the result of BEEP.EVERY.6.SECONDS working in the background as an interrupt.  Unlike the polling example presented above, the processor is now spending a very small fraction of its available time performing the timing function.  This example demonstrates the benefits of interrupts, and how QED-Forth simplifies their use.

Summary of the 16-Bit Free Running Counter

The heart of the programmable timer subsystem is a free-running 16-bit counter whose count is available in the read-only TCNT register.  The range and resolution of counts in the timer count register are determined by prescaler bits PR0 and PR1 in the TMSK2 register.  Each time the timer count register overflows, the processor sets the timer overflow flag TOF in the TFLG2 register.  If the timer overflow interrupt mask bit TOI in the TMSK2 register has been set, an interrupt is triggered when the TCNT register overflows.  To service this interrupt, a handler must be installed which clears the timer overflow flag in addition to performing its intended task.

The example program presented above is by no means the best way to measure time intervals. Nevertheless, it illustrates three important concepts: use of the free running count register, the implementation of interrupts via a flag and an interrupt enable mask (TOF and TOI), and the responsibility of the interrupt handler to clear its interrupt flag by storing a 1 in the flag’s location.

Configuring and Using Input Capture Functions

Four input capture functions are available to measure input pulse widths and periods, synchronize program execution with external devices, and expand the number of available external hardware interrupts.  External input signals are interfaced to the input captures via four PORTA pins PA0, PA1, PA2 and PA3.  When an active input capture senses a specified signal transition on its PORTA pin, the time of occurrence is saved in a 16-bit register.  An optional interrupt can be triggered in response to the signal transition event.  Three types of transitions can be sensed:

                                                                                                                                                                                                                                                                                                                                                                                      Rising edges

                                                                                                                                                                                                                                                                                                                                                                                      Falling edges

                                                                                                                                                                                                                                                                                                                                                                                      All rising and falling edges

The following five steps set up an input capture function that calls an associated interrupt service routine.  If interrupts are not being used (for example, if the interrupt capture flag bit is being polled), steps 2 and 4 may be skipped.

                                                                                                                                                                                           0.                                                                                                                                                                                           Configure the PORTA pin associated with the input capture as an input by writing a 0 to its bit position in the PORTA data direction register, named PORTA.DIRECTION in QED-Forth.

                                                                                                                                                                                           0.                                                                                                                                                                                           (Optional). Define an interrupt service routine and install it using ATTACH.

                                                                                                                                                                                           0.                                                                                                                                                                                           Clear the input capture’s flag bit.

                                                                                                                                                                                           0.                                                                                                                                                                                           (Optional). Enable (set) the input capture’s local interrupt mask.

                                                                                                                                                                                           0.                                                                                                                                                                                           Enable the input capture function by setting its edge trigger control bits.

When a specified signal edge is sensed, the value in the timer count (TCNT) register is latched into a 16-bit register associated with the input capture, and the input capture’s interrupt flag is set by the processor.  If the input capture’s interrupt mask is also enabled, the interrupt is recognized and the installed interrupt service routine is called.

The secondary serial port supported by QED-Forth’s software UART uses PORTA pin PA3 (associated with IC4/OC5) as the serial input and PA4 (associated with OC4) as the serial output.  If you need the services of the secondary serial port make sure that you do not use these pins or compare functions.

Configuring Port A Pins For Input Capture

To configure Port A pins PA0, PA1, and PA2 for input capture, their data direction bits in Port A’s data direction register (bits 0, 1, and 2,  respectively) must be cleared. The data direction register is called DDRA in Appendix B, and is named PORTA.DIRECTION in QED-Forth.  These bits are cleared upon reset.  The sample routines presented here explicitly clear them to ensure that the input capture pins are properly configured.

PORTA pin PA3 can be used for either input capture or output compare (output compare functions are described later in this chapter).  To use PA3 as input capture #4, the I4/O5 bit in the pulse accumulator control register, PACTL, must be set (MC68HC11F1 Technical Data Manual,  p.7-12).  Note that if port bit PA3 is configured as an input capture by setting I4/O5, and if PA3 is configured as an output by setting data direction bit 3 in PORTA.DIRECTION, then changes on the PA3 output signal will activate the input capture function.  This could be useful in some applications.

Enabling Input Capture Functions for Specified Signal Transitions

Each input capture function is enabled by two “edge” bits which determine the signal transition to be sensed.  These bits are named EDGxA and EDGxB (where x = 1...4 specifies the input capture number).  The following table relates the edge bits and input capture number to the associated PORTA pin:

Table 8‑5                                                                                                                                                                                           Enter your Table Caption here.

The edge bits are located in timer control register 2, named TCTL2  (MC68HC11F1 Technical Data Manual,  pp.7-1...7-3, M68HC11 Reference Manual,  pp.10-16...10-19).   The meanings of the edge bits are as follows:

Table 8‑5                                                                                                                                                                                           Enter your Table Caption here.

Note that clearing both edge bits disables the input capture function.

Input Capture Utility Words

The following QED-Forth words demonstrate how to configure each input capture function. First we define register names and useful constants:



HEX      \ set number base to hexadecimal

8021 REGISTER: TCTL2 \ timer control reg. #2, holds edge specification bits

8023 REGISTER:   TFLG1 \ timer interrupt flag register

8026 REGISTER:  PACTL \ pulse accumulator control register,

      \ configures PA3 as input capture

4 CONSTANT I4/O5.MASK \ mask for bit that configures PA3 as an input capture



\ Define flags to specify the signal events that trigger the input capture:

0  CONSTANT DISABLE.CAPTURE   \ disable an input capture

1  CONSTANT RISING.EDGE \ capture a rising edge

2 CONSTANT FALLING.EDGE   \ capture a falling edge

3 CONSTANT ANY.EDGE \ capture either a rising or falling edge



\ Define some input capture identification constants:

0 CONSTANT IC3/PA0        \ input capture 3, associated with PA0

1  CONSTANT IC2/PA1        \ input capture 2, associated with PA1

2  CONSTANT IC1/PA2        \ input capture 1, associated with PA2

3  CONSTANT IC4/PA3        \ input capture 4, associated with PA3

The next word, CONFIGURE.INPUT.CAPTURE, configures and enables a given input capture function to sense a signal change event.  The processor sets the input capture’s flag bit when the specified event is detected:

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

: CONFIGURE.INPUT.CAPTURE  ( signal.event.flag\input.capture.id -- )

   LOCALS{ &input.capture.id &sense.event }

 \ Configure the input capture function...

   1 &input.capture.id SCALE PORTA.DIRECTION    \ make PAx an input

 CLEAR.BITS  \ by clearing the direction bit

 &input.capture.id IC4/PA3 =   \ If it’s IC4/PA3...

   IF  I4/O5.MASK PACTL SET.BITS \ make it an input capture

   ENDIF

   \ Now, enable the input capture function...

 1 &input.capture.id SCALE TFLG1 C!  \ Clear the ICx flag, see below...

 3 &input.capture.id 2* SCALE TCTL2 CLEAR.BITS   \ Clear EDGxA and EDGxB bits

 &sense.event &input.capture.id 2* SCALE TCTL2 SET.BITS

        \ Set EDGxA and EDGxB to enable the input capture

;



CONFIGURE.INPUT.CAPTURE lets you configure and enable any of the four input captures to sense a signal change event.  All you need to do is decide which input capture function you will use, and which signal transition you want to sense.  For example, the following statement configures input capture 3 to detect a falling edge on PORTA pin 0:

FALLING.EDGE IC3/PA0  CONFIGURE.INPUT.CAPTURE

Capturing rising edges on PORTA pin 3 using input capture 4 is accomplished by executing:

RISING.EDGE IC4/PA3  CONFIGURE.INPUT.CAPTURE

The following word disables an input capture:



: DISABLE.INPUT.CAPTURE ( input.capture.id -- )

   DISABLE.CAPTURE SWAP CONFIGURE.INPUT.CAPTURE

   ;

To disable the input captures #3 and #4, execute:

IC3/PA0  DISABLE.INPUT.CAPTURE

IC4/PA3 DISABLE.INPUT.CAPTURE

Input Capture Interrupts

Using CONFIGURE.INPUT.CAPTURE (defined above) we can configure and enable any input capture function to detect a signal transition event.  When the event occurs, the contents of the timer count (TCNT) register are latched into a 16-bit register associated with the input capture function.  These timer input capture registers are named TIC1, TIC2, TIC3, and TI4O5 (see Figure 7-1 in MC68HC11F1 Technical Data Manual,  p.7-2, and M68HC11 Reference Manual, pp.10-15...10-16).  They are read-only registers and are typically accessed using the QED-Forth command @.

When a signal change event is sensed, the processor sets the input capture’s interrupt flag. The input capture interrupt flags are named IC1F, IC2F, IC3F, and IC4F and are located in the timer flag 1 register, TFLG1 (MC68HC11F1 Technical Data Manual, p.7-8, M68HC11 Reference Manual,  p.10-16).  Like other interrupt flags, input capture interrupt flags are cleared by writing a 1 to them.  An input capture triggers an interrupt if its local interrupt mask has been set.  Input capture interrupt masks are named IC1I, IC2I, IC3I, and IC4I and are located in the timer mask register TMSK1 (MC68HC11F1 Technical Data Manual,  p.7-7, M68HC11 Reference Manual,  p.10-16).

Input capture events should be serviced and the flag reset before the next specified signal transition occurs.  If the input capture register is not read before the next specified transition, the originally stored timer count will be written over. If the input capture flag is not reset quickly enough, a signal transition may be missed.

Input Signal Pulse Width Measurement

The following software routines demonstrate how to use interrupts triggered by input capture 1 to measure input pulse widths.  Although a very simple software example could be constructed, we present a more complex example in order to point out some useful programming techniques.  The example shows how to use assembly coded service routines to achieve fast response, how to combine input capture and timer overflow interrupts to measure long pulse widths, and how to call floating point functions from inside an interrupt routine.

Some of the routines in this example use functions defined in the previous section named “Input Capture Utility Words”.  As usual, we start by assigning names to relevant control registers.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

HEX \ use hex base to specify addresses

8 WIDTH !                  \ save more characters in names

                   \ to avoid non-unique names



8010   REGISTER: TIC1           \ IC1’s 16-bit timer capture register

8012   REGISTER: TIC2           \ IC2’s 16-bit timer capture register

8014   REGISTER: TIC3           \ IC3’s 16-bit timer capture register

801E   REGISTER: TI4O5          \ IC4’s 16-bit timer capture register

8022   REGISTER: TMSK1       \ timer interrupt mask register #1

8023   REGISTER: TFLG1       \ timer interrupt flag register #1

8025   REGISTER: TFLG2       \ timer interrupt flag register #2



RISING.EDGE CONSTANT HIGH.PULSE  \ flag to time width of high pulse

FALLING.EDGE CONSTANT LOW.PULSE   \ flag to time width of low pulse



HEX

8000   CONSTANT REGISTER.BASE     \ base address of register block

  10  CONSTANT +TIC1          \ byte offset to TIC1 register

  21 CONSTANT +TCTL2         \ byte offset to TCTL2 register

  22   CONSTANT +TMSK1 \ byte offset to TMSK1 register

  23   CONSTANT +TFLG1         \ byte offset to TFLG1 register

  24   CONSTANT +TMSK2         \ byte offset to TMSK2 register

  25   CONSTANT +TFLG2         \ byte offset to TFLG2 register

   4   CONSTANT IC1.MASK       \ mask to set and clear IC1F and IC1I

  30   CONSTANT EDGE.TOGGLE    \ mask to toggle rising/falling edge

  80    CONSTANT TIMER.OVERFLOW.FLAG  \ mask to isolate the TOF bit

                     \ in the TFLG2 register



VARIABLE LEADING.EDGE.TIME    \ variable to store TCNT of leading edge

VARIABLE #TIMER.OVERFLOWS     \ keeps a running count of overflows



As explained earlier in the chapter, the timer count (TCNT) register overflows every 131.1 ms given the default settings of prescale bits PR0 and PR1 in the TMSK2 register.  Unless we keep track of these timer overflows, we will be limited to pulse measurements of less than 131.1 ms.  To extend the measurable pulse length to 2.4 hours, we count the number of timer overflows using this interrupt handler:

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

HEX

: TIMER.OVERFLOW.COUNTER ( -- )

   TIMER.OVERFLOW.FLAG TFLG2 C!  \ reset the TOF (timer overflow) flag

   1 #TIMER.OVERFLOWS +!         \ increment the counter

;



This routine is installed as an interrupt handler by PULSE.WIDTH.TIMER.INIT below.

Next we define PULSE.WIDTH.MEASURER.  This word services interrupts that are triggered by a desired edge event.  PULSE.WIDTH.MEASURER expects IC1/PA2 to be configured to capture the leading edge of a pulse.  Thus IC1/PA2 should be triggered on a rising edge to measure a high pulse, or triggered on a falling edge to measure a low pulse.  The timer overflow interrupt handler, TIMER.OVERFLOW.COUNTER, must be installed, but its interrupt mask bit, TOI, should initially be cleared (interrupt disabled).  PULSE.WIDTH.MEASURER controls the TOI mask bit so that timer count register overflows are counted only while a pulse is being measured.  In this example, TOI is used to determine whether a sensed transition is a leading or trailing edge.  The algorithm is as follows:

Initial Conditions:

Input capture 1’s interrupt mask & interrupt flag are both set: IC1I = IC1F = 1

Algorithm implemented by IC1/PA2’s interrupt service routine:

                                                                                                                                                                                           0.                                                                                                                                                                                           Clear input capture 1’s IC1F flag which triggered the interrupt.

                                                                                                                                                                                           0.                                                                                                                                                                                           Invert each of the EDG1A and EDG1B bits to make IC1/PA2 sensitive to the next edge. That is, if the current input capture was triggered by a rising edge, set the edge bits to detect a falling edge, and vis versa.

                                                                                                                                                                                           0.                                                                                                                                                                                           Save the captured edge’s TCNT time on the QED-Forth data stack.

                                                                                                                                                                                           0.                                                                                                                                                                                           Check the state of the TOI bit to determine if the captured edge is a leading edge (TOI = 0 because the timer overflow interrupt is initially disabled) or trailing edge (TOI = 1 because the timer overflow interrupt is enabled after the leading edge).

                                                                                                                                                                                            .                                                                                                                                                                                           If TOI = 0, a leading edge has been sensed: Clear the TOF bit to keep track of timer overflows;  Set the TOI bit to track timer overflows and to indicate that the next edge is trailing;  Save TCNT from stack into the LEADING.EDGE.TIME variable.

                                                                                                                                                                                            .                                                                                                                                                                                           If TOI = 1, a trailing edge has been sensed:  Clear the TOI bit to disable timer overflow interrupts;  Compute the pulse width in milliseconds (ms);  Print the result;  Reset #TIMER.OVERFLOWS for the next pulse.

                                                                                                                                                                                           0.                                                                                                                                                                                           Return from subroutine.  (Note: QED-Forth interrupt handlers return using ; or RTS, not RTI.  The ATTACH handler supplies the required RTI).

This algorithm is implemented in the code presented below.  The computation and printing of the result are performed by the high-level word COMPUTE.PULSE.WIDTH.  The assembly coded interrupt service routine PULSE.WIDTH.MEASURER handles the time-critical tasks and then calls COMPUTE.PULSE.WIDTH.  For less demanding applications, the interrupt service routine could also be coded in high level.

The code minimizes the time spent servicing a leading edge interrupt so short-duration pulses can be measured.  The calculation and printing of the result performed after the trailing edge of the input pulse is more time consuming, and limits this example to measuring low frequency pulse trains.

Handling higher frequency signals could easily be accomplished by rapidly storing the timer and overflow counts in an array and then performing the time-intensive computation and printing tasks when more time is available.  In a multitasked system these time consuming functions are best performed by a “foreground” task that accepts and processes saved data collected by the “background” interrupt routine.  This keeps the interrupt routines short and efficient and keeps the structure and real-time behavior of the application modular and easy to maintain.

Note that COMPUTE.PULSE.WIDTH calls the matched pair of routines FP&STRING.PUSH and FP&STRING.POP which save and restore all of the scratchpad user variables needed to perform floating point calculations and printing of floating point numbers.  These utilities should be called whenever floating point routines are used inside an interrupt handler, as they prevent the corruption of any floating point operation that might be running in the main program.  If an interrupt performs floating point calculations without calling printing or string conversions, the faster save routines FP.PUSH and FP.POP may be used.  Please consult the glossary for a full explanation of these routines.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

DECIMAL \ set number base

48 VALLOT                  \ save 48 bytes in variable area

VHERE    XCONSTANT TEMPORARY.PAD \ declare temporary RAM scratchpad

                   \ for F. which uses 32 bytes below PAD

2E-3     FCONSTANT MS/TCNT       \ each TCNT count = 2E-3 ms

131.1   FCONSTANT MS/OVERFLOW      \ each timer overflow = 131.1 ms



: COMPUTE.PULSE.WIDTH ( falling.edge.TCNT.value -- )

\ this routine computes and prints the pulse width based on the falling-edge

\ TCNT value, the saved leading-edge TCNT value, and the number of

\ timer overflows since the leading edge.

\ Formula: pulse width = end.time - start.time,

\ where:   end.time = (falling.edge.TCNT * ms/TCNT) + (#overflows * ms/overflow)

\       start.time = leading.edge.TCNT * ms/TCNT

\ NOTE: some of the lines are keyed to the algorithm steps presented above

 TEMPORARY.PAD FP&STRING.PUSH  \ save fp scratchpad variables so they

         \ aren’t changed during the interrupt;

         \ see glossary entry for FP&STRING.PUSH

  UFLOT    \ convert trailing TCNT to positive fp#

  MS/TCNT F*  \ convert trailing edge TCNT to ms

 #TIMER.OVERFLOWS @ FLOT

   MS/OVERFLOW F* F+ ( -- end.time.in.ms )

  LEADING.EDGE.TIME @ UFLOT  \ convert leading edge TCNT to positive fp#

 MS/TCNT  F* \ convert t.start to ms

  F-       \ 4.b.2: pulse ms = t.end - t.start

   CR .” Pulse Width = “ F.  .” ms”    \ 4.b.3: print result

  #TIMER.OVERFLOWS OFF \ 4.b.4: reset overflow counter

 FP&STRING.POP  \ restore floating point user variables

;





CODE PULSE.WIDTH.MEASURER     ( -- )

\ this is the input capture’s interrupt service routine.

\ NOTE: some of the lines are keyed to the algorithm steps presented above

  REGISTER.BASE  IMM LDX   \ load X with base addr of control registers

   IC1.MASK IMM   LDAA \ load accumulator A with IC1F mask

   +TFLG1   IND,X STAA \ 1. clear the interrupt flag bit IC1F

   EDGE.TOGGLE IMM LDAA  \ load sense event toggle mask into A

 +TCTL2   IND,X EORA  \ invert edge bits...

  +TCTL2   IND,X STAA \ 2. ...which alternates the edge trigger

   +TIC1 IND,X LDD   \ get latched TCNT when edge event occurred

       DEY   \ make room on data stack

        DEY

  0  IND,Y STD   \ 3. place latched timer result on data stack

  +TMSK2   IND,X LDAA \ 4.b if MSB of TMSK2 (TOI) is set,

   MI IF,            \ then the transition is a trailing edge

                  \ 4.b.1 clear the TOI mask

         TIMER.OVERFLOW.INTERRUPT.MASK +TMSK2 IND,X  BCLR

        CALL COMPUTE.PULSE.WIDTH  \ print the result

     ELSE,          \ else the transition is a leading edge

TIMER.OVERFLOW.FLAG  IMM   LDAA  \ put bit mask into A

        +TFLG2 IND,X STAA  \ 4.a.1 clear TOF flag

TIMER.OVERFLOW.INTERRUPT +TMSK2 IND,X  BSET

                      \ 4.a.2 set TOI

>FORTH            \ go to QED-Forth to store

LEADING.EDGE.TIME !  \ 4.a.3 store leading edge time

       >ASSM

      THEN,

   RTS               \ 5. return from subroutine; note the use of RTS, not RTI

END.CODE

Notice the technique used to clear the IC1F flag in step 1. and the TOF flag in step 4.a.1.  In assembly, a BSET instruction will not properly reset the TOF bit (nor will a SET.BITS command) even though it is necessary to store a 1 in TOF to clear it.  For an important discussion of this matter see M68HC11 Reference Manual,  p. 10-14, section 10.2.4: Tips for Clearing Timer Flags.  Using QED-Forth, the easiest way to reset a flag bit is to store a 1 in the appropriate position using C!.

We now define PULSE.WIDTH.TIMER.INIT to initialize and install PULSE.WIDTH.MEASURER and TIMER.OVERFLOW.COUNTER.  After executing PULSE.WIDTH.TIMER.INIT, IC1/PA2 waits for the appropriate signal transition and then times the signal’s pulse width. After the pulse’s trailing edge has been detected, its width is computed and displayed.  IC1/PA2 continues measuring pulse widths until

IC1/PA2 DISABLE.INPUT.CAPTURE

is executed.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

: PULSE.WIDTH.TIMER.INIT   ( low.or.high.pulse -- )

  IC1.MASK  TMSK1 CLEAR.BITS      \ disable IC1 interrupts

TIMER.OVERFLOW.INTERRUPT.MASK  TMSK2  CLEAR.BITS   \ disable TOI

 CFA.FOR PULSE.WIDTH.MEASURER  IC1.ID  ATTACH      \ install handlers

  CFA.FOR TIMER.OVERFLOW.COUNTER  TIMER.OVERFLOW.ID  ATTACH

 #TIMER.OVERFLOWS OFF         \ clear overflow counter

 IC1/PA2 CONFIGURE.INPUT.CAPTURE \ set IC1/PA2 up for leading edge

  IC1.MASK  TMSK1 SET.BITS     \ set IC1I mask bit

;

We can now measure pulse widths using input capture 1.  To test this capability, we can use PORTA pin 7 (PA7) as an input pulse signal source by connecting it to input capture 1’s PORTA pin PA2.  After connecting these pins together, type the following to prepare for testing the pulse width timer:



HEX

80    CONSTANT PA7.MASK \ PA7 is the top bit of PORTA



: PA7.ON ( -- | set output bit 7 of PORTA HIGH )

   PA7.MASK PORTA SET.BITS \ set bit PA7 to output a HIGH signal

;



: PA7.OFF ( -- | set output bit 7 of PORTA LOW )

   PA7.MASK PORTA CLEAR.BITS  \ clear bit PA7 to output a LOW signal

;



: PREPARE.TO.MEASURE ( high/low.pulse.test -- )

PULSE.WIDTH.TIMER.INIT     \ install and prep interrupt handlers

   ENABLE.INTERRUPTS \ ensure interrupts are enabled

;



Using PORTA pin 7 to control the pulse signal to input capture 1 via PORTA pin 2, we can measure a HIGH pulse by typing the following:



PA7.MASK PORTA.DIRECTION SET.BITS   \ configure PA7 for digital output



PA7.OFF             \ measuring a HIGH pulse requires a LOW start

HIGH.PULSE PREPARE.TO.MEASURE   \ install pulse measurer & enable interrupts

PA7.ON   \ Send the leading edge of the HIGH pulse and begin timing.

PA7.OFF  \ End the pulse.  The PULSE.WIDTH.MEASURER will print

      \ the duration of the pulse that you created.

     \ Iterating this sequence of PA7.ON and PA7.OFF will allow

    \ measurement of additional HIGH pulses



IC1/PA2 DISABLE.INPUT.CAPTURE   \ call this when you are done, or desire to

                \ measure LOW pulses



Measuring a LOW pulse is accomplished as follows:



PA7.ON               \ measuring a LOW pulse requires a HIGH start

LOW.PULSE PREPARE.TO.MEASURE \ install pulse measurer & enable interrupts

PA7.OFF              \ send the leading edge to begin timing

PA7.ON              \ send the trailing edge to get a result



IC1/PA2 DISABLE.INPUT.CAPTURE \ call this when you are done, or desire

                \ to measure HIGH pulses





Summary of the Input Capture Functions

The 68HC11F1 has four input captures that sense signal transitions on PORTA pins PA0, PA1, PA2, and PA3.  When an input capture senses an input event, it records the contents of TCNT in its 16-bit input capture register and sets its (interrupt) flag in TFLG1.  If the input capture’s local interrupt mask in TMSK1 is set, an interrupt is recognized when each specified edge is detected.  Two input capture edge control bits in TCTL2 enable each input capture and select the edge which triggers the input capture.  To use input capture 4, a configuration bit named I4/O5 in the PACTL register must be set.

The following five steps set up an input capture function that calls an associated interrupt service routine.  If interrupts are not being used, steps 2 and 4 may be skipped.

                                                                                                                                                                                           0.                                                                                                                                                                                           Configure the PORTA pin associated with the input capture as an input by writing a 0 to its bit position in the PORTA data direction register, PORTA.DIRECTION.

                                                                                                                                                                                           0.                                                                                                                                                                                           (Optional). Define an interrupt service routine and install it using ATTACH.

                                                                                                                                                                                           0.                                                                                                                                                                                           Clear the input capture’s flag bit.

                                                                                                                                                                                           0.                                                                                                                                                                                           (Optional). Enable (set) the input capture’s local interrupt mask.

                                                                                                                                                                                           0.                                                                                                                                                                                           Enable the input capture function by setting its edge trigger control bits.

This flexible subsystem is capable of measuring input pulse widths, synchronizing program execution with external devices, and expanding the number of available external interrupts.

Overview of the Output Compare Functions

The programmable timer subsystem provides 5 output compare functions.  Each of these functions can automatically call an interrupt routine and/or change the state of an associated PORTA pin when the value in a specified register matches the count in the TCNT timer register.  Thus the programmer can precisely specify a future time (we’ll call it time T) at which an action will occur.  Using output compares, it is easy to set up real-time clocks, cause periodic execution of code, and generate precisely timed synchronous or asynchronous waveforms on PORTA outputs PA3 through PA7.

An active output compare function can cause a signal change on a PORTA pin at a specified time T, and/or trigger an interrupt at time T.  To cause a signal change on a PORTA pin when time T equals the contents of TCNT, the PORTA pin must be configured as an output, and the output compare function must be enabled.  The output compare function is enabled by storing a 2-bit code specifying the desired signal change.  To trigger an interrupt when time T = TCNT, an interrupt handler must be installed, and the output compare’s local interrupt must be enabled.

Each output compare (OC) function has a 16-bit timer compare register which holds the specified time T, an output compare (interrupt) flag, an output compare interrupt mask, and two signal edge configuration bits (OC1 does not have the configuration bits).  The two signal edge configuration bits are discussed in greater detail later.  The timer output compare registers, named TOC1, TOC2, TOC3, TOC4 and TOC5, each hold a 16-bit value which is compared with the current value in the timer count register TCNT (MC68HC11F1 Technical Data Manual, p.7-4, M68HC11 Reference Manual,  pp.10-27...10-31).  When the values are equal (i.e. when a successful output compare occurs), the processor sets the output compare’s interrupt flag.  This flag is named OCxF (x = 1...5) and is located in the TFLG1 register (MC68HC11F1 Technical Data Manual,  p.7-8). An interrupt is recognized if the output compare’s interrupt mask is also set. The interrupt mask is named OCxI and is located in the TMSK1 register.

The secondary serial port supported by QED-Forth’s software UART uses PORTA pin PA3 (associated with IC4/OC5) as the serial input and PA4 (associated with OC4) as the serial output.  If you need the services of the secondary serial port make sure that you do not use these pins or compare functions.  The timeslicer uses output compare 2, so if you need the services of the timeslicer (timesliced task switching, elapsed time clock, or BENCHMARK: function) make sure that you do not use OC2 for other functions.  Pin PA6 which is associated with OC2 and OC1 is available for use as a general purpose digital I/O pin, or as an output signal controlled by OC1.

The following sections describe how to use output compares to generate clocks, pulse trains, “one-shot” pulse signals, and synchronized pulsed waveforms.

Generating Accurate Clocks and Periodic Interrupts

The following example illustrates the use of an output compare function to periodically execute an interrupt service routine.  We’ll use output compare 1 (OC1) to generate elapsed-time clocks and to activate a simple alarm that beeps after a specified period has elapsed.

This example illustrates the very useful technique of generating cascaded clocks so that long time intervals can be represented.  At its default frequency, the 68HC11’s free-running timer TCNT overflows (resets to a count of 0) every 131 ms.  But we often need to measure much longer time intervals.  Moreover, it is often necessary to generate continuously updated clock variables whose contents represent an elapsed time expressed in convenient time units such as milliseconds or seconds.

The solution is to use an output compare to implement a clock that has a period less than 131 ms; in this example we choose a period of 10 ms.  We then use this clock to increment a higher level clock that counts in larger time units (1 second in this example).  Each “clock” is simply a variable whose contents are periodically incremented by the output compare’s interrupt service routine. The contents of the clocks can be read by any program at any time, providing an accurate reading of the time that has elapsed since the clocks were initialized.

In this example, the OC1 interrupt service routine increments a variable named 10MS.CLOCK until it reaches a value of 100.  Realizing that 1 second has now elapsed, the interrupt service routine clears the 10MS.CLOCK variable and increments a variable named 1SECOND.CLOCK.  External programs can read the contents of the two clocks to calculate elapsed time intervals in seconds, with a 10 ms time resolution.

In fact, the elapsed time counter that is driven by QED-Forth’s timeslice multitasker uses this technique.  It implements a 5 ms clock generated by OC2 that in turn increments a 32-bit clock every second.  The QED-Forth words READ.ELAPSED.TIME and READ.ELAPSED.SECONDS report the current values of these clocks; see their glossary entries for details.

The example begins with definitions of control registers and bit masks needed by the alarm.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

\ Define Timer Output Compare Register Addresses:

HEX                  \ use hexadecimal number base

800E  REGISTER: TCNT        \ Timer counter register

8016  REGISTER: TOC1        \ Output compare 1 register

8018  REGISTER: TOC2        \ Output compare 2 register

801A  REGISTER: TOC3        \ Output compare 3 register

801C  REGISTER: TOC4        \ Output compare 4 register

801E  REGISTER: TI4O5       \ Output compare 5 (also used for IC4)

8022  REGISTER: TMSK1    \ timer interrupt mask register #1

8023  REGISTER: TFLG1    \ timer interrupt flag register #1



80    CONSTANT OC1.MASK \ isolates OC1 interrupt flag & mask bits

DECIMAL              \ go to decimal number base

5000  CONSTANT 10MS        \ 10 ms = 5000 counts of the TCNT timer

100   CONSTANT 1SECOND \ 1 second = 100 counts on the 10ms clock



VARIABLE 10MS.CLOCK        \ is incremented every 10 ms by OC1

VARIABLE 1SECOND.CLOCK     \ is incremented every second by OC1

VARIABLE ALARM.SET.POINT      \ alarm sounds when this = 1.SECOND.CLOCK



\ DISABLE.ALARM turns the alarm off by clearing OC1’s interrupt mask.

: DISABLE.ALARM ( -- )

   OC1.MASK TMSK1 CLEAR.BITS  \ disable OC1 interrupts

;



\ OC1.ALARM is the interrupt service routine for output compare 1.

\ It clears OC1’s interrupt flag, updates its timer compare

\ register with the time at which the next interrupt should occur

\ (10 ms from now), and increments the 10ms clock.  If the 10ms clock reads

\ 100, then 1 second has elapsed, so the 10ms clock is cleared and the 1second

\ clock is incremented. If the 1second clock equals the alarm set point,

\ the routine BEEPs and disables the output compare’s interrupt

\ which stops the clocks.

: OC1.ALARM

   OC1.MASK TFLG1 C!       \ clear the OC1 interrupt flag

   10MS TOC1 +!            \ update TOC1 for next interrupt

   1 10MS.CLOCK +!            \ increment 10 ms clock

   10MS.CLOCK @ 1SECOND =    \ has 1 second elapsed?

   IF 10MS.CLOCK OFF       \ if so, clear 10ms clock

      1 1SECOND.CLOCK +!      \ increment 1second clock

      1SECOND.CLOCK @

      ALARM.SET.POINT @ =        \ is it time to sound alarm?

      IF DISABLE.ALARM     \ if it is, turn interrupt off

         BEEP \ and beep to indicate that time is up

      ENDIF

   ENDIF

;



\ SET.ALARM installs OC1’s interrupt handler, initializes the alarm set point

\ and clock variables, and enables OC1’s interrupt mask.

: SET.ALARM ( time.until.alarm.in.seconds -- )

   ALARM.SET.POINT !       \ initialize set point

   10MS.CLOCK OFF          \ reset 10 ms clock

   1SECOND.CLOCK OFF       \ reset 1 second clock

   TCNT @ 10MS + TOC1 !       \ set time for first interrupt to occur

DISABLE.ALARM           \ disable OC1 interrupts

   CFA.FOR OC1.ALARM OC1.ID ATTACH  \ install OC1.ALARM

   OC1.MASK TFLG1 C!       \ reset OC1 interrupt flag

   OC1.MASK TMSK1 SET.BITS    \ enable OC1I interrupt mask bit

ENABLE.INTERRUPTS       \ globally enable interrupts

;



For example, to set the alarm to sound in ten seconds type:

DECIMAL

10 SET.ALARM

The computer will beep when ten seconds have elapsed.  This timer is much more flexible and accurate than the timer overflow alarm that was presented earlier in the chapter.



Generating Output Pulse Signals

In addition to triggering an interrupt, a successful output compare can cause a signal change on a PORTA output pin.  Output compares OC2 through OC5 can toggle, clear, or set their associated output pins.  A pair of bits associated with each output compare determines the action to be performed.  These bits are named OMn (output mode) and OLn (output level) where n = 2, 3, 4, or 5.  The bits are located in timer control register 1, TCTL1 (MC68HC11F1 Technical Data Manual, p.7-7, M68HC11 Reference Manual,  pp.10-31...10-33).  The following table describes the settings of OMn and OLn bits for a desired signal change effect:



The output compare function’s OMn and OLn bits are both initialized to 0 after a reset; thus, all output compare functions are initially disabled.  If either OMn or OLn is set, the output compare controls the associated output pin.  These bits override the direction configuration bits in the PORTA.DIRECTION register.  When either the OMn or OLn bit associated with a PORTA pin is set, the PORTA pin is forced to be an output.  When OMn and OLn are both cleared, the PORTA pin reverts to the configuration specified by the PORTA data direction register PORTA.DIRECTION.

PORTA pin PA3 may be used as output compare 5, or as input capture 4.  To configure PA3 for use by output compare 5, clear the I4/O5 bit in the PACTL (pulse accumulator control) register by executing:

8026  REGISTER: PACTL\ define pulse accumulator control register

4   CONSTANT I4/O5.MASK  \ define mask for bit that configures PA3

I4/O5.MASK PACTL CLEAR.BITS   \ clear the I4/O5 bit

This is the only special treatment required to properly use OC5; otherwise, OC5 operates exactly the same as OC2, OC3, and OC4.  Recall that IC4/OC5 is used by the secondary serial port; you can use IC4/OC5 if you don’t need the services of the second RS232 serial link.

A One-Shot Output Pulse Generator

The following example demonstrates how to generate a single (“one-shot”) HIGH or LOW pulse of specified width on PORTA bit PA5 using OC3.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

HEX \ set hexadecimal number base

801A  REGISTER: TOC3           \ output compare 3 count register

8020 REGISTER: TCTL1       \ timer control register #1

8022 REGISTER: TMSK1       \ timer interrupt mask register #1

8023   REGISTER: TFLG1       \ timer interrupt flag register #1



1     CONSTANT HIGH.PULSE     \ flag to output a high pulse

2     CONSTANT LOW.PULSE      \ flag to output a low pulse



\ Define output mode configuration flags and masks that specify action

\ to be performed when a successful output compare occurs:

20     CONSTANT PA5.MASK    \ mask for setting/resetting PA5

20    CONSTANT OC3.MASK    \ to set/clr OC3 interrupt flag & mask

30    CONSTANT SET.OUTPUT     \ OM3/OL3 mask in TCTL1; action=set

20    CONSTANT CLEAR.OUTPUT   \ OM3/OL3 mask in TCTL1; action=clear

10     CONSTANT TRAILING.EDGE.MASK \ OM/OL3 mask in TCTL1;action=toggle



DECIMAL

500. FCONSTANT COUNTS/MS      \ number of TCNT counts per ms

131. FCONSTANT MAX.PULSE.WIDTH  \ we’ll limit pulse width to 131 ms



INTEGER: PULSE.WIDTH       \ a self-fetching variable, holds the pulse

                  \ width expressed as a number of TCNT counts



 CODE OC3.ONE.SHOT  ( -- )

\ This assembly routine is the interrupt service code for OC3.  It is called on

\ the leading edge of the pulse.  The output compare hardware automatically

\ sets the PA5 bit to the appropriate level at the same time that this routine

\ is called.  This routine resets the interrupt flag, updates the TOC3 register

\ so that the output compare will be activated at the falling edge of the pulse,

\ configures OM3 and OL3 in the TCL1 register to toggle the current state of

\ PA5 the next time the output compare is successful (which is at

\ the trailing edge of the pulse), and disables the interrupt mask so that

\ this routine will not be called at the falling edge of the pulse.  Note that

\ the processor’s output compare hardware will automatically toggle the

\ PA5 signal to end the pulse, even though the interrupt is not enabled!

   OC3.MASK IMM LDAA     \ load mask needed to reset OC3F

   TFLG1 DROP  EXT STAA     \ clear the OC3F interrupt flag

 CALL  PULSE.WIDTH    \ push interval time on stack

   0     IND,Y LDD \ load increment value into ACCD

            DEY      \ drop value from data stack

          DEY      ( -- )

  TOC3  DROP  EXT ADDD  \ t.compare = TOC3 + PULSE.WIDTH

   TOC3  DROP  EXT STD      \ store the result in TOC3

   TCTL1 DROP  EXT LDAA     \ load leading edge trigger

TRAILING.EDGE.MASK IMM   EORA  \ trailing edge = leading XOR mask

 TCTL1 DROP  EXT STAA     \ store next edge into TCTL1

OC3.MASK NOT    IMM   LDAA \ load mask to turn off interrupt OC3I

   TMSK1 DROP EXT ANDA \ force OC3I to zero

   TMSK1 DROP EXT STAA     \ store to TMSK1 turns interrupt off

 RTS               \ return; note that ATTACH supplies the RTI

END.CODE

: ONE.SHOT   ( high.or.low.pulse.flag\fp.pulse.width.in.ms  -- )

\ note that the pulse width must be less than MAX.PULSE.WIDTH which is 131 ms.

\ This routine ATTACHes the interrupt service routine for OC3,

\ converts the specified pulse width in ms to TCNT count units, stores the

\ result in PULSE.WIDTH, and configures the OC3 hardware for a low-to-high

\ transition if a HIGH.PULSE is specified, or a high-to-low transition if a

\ LOW.PULSE is specified.  It then sets up OC3 so that the first successful

\ compare will occur in 10 ms, and enables the OC3 interrupt mask.

   OC3.MASK TMSK1 CLEAR.BITS     \ disable OC3 interrupts

  SET.OUTPUT TCTL1 CLEAR.BITS      \ clear OM3 & OL3 to disable pin logic

   CFA.FOR OC3.ONE.SHOT OC3.ID ATTACH  \ install OC3.ONE.SHOT

 FDUP MAX.PULSE.WIDTH F< \ make sure pulse width is < max

   IF COUNTS/MS F* UFIXX      \ convert value to TCNT counts

     TO PULSE.WIDTH       \ save number of counts in pulse.width

   ELSE  BEEP

      CR .” Pulse width must be less than “  MAX.PULSE.WIDTH F.   .” ms”

    ABORT

   ENDIF

   PA5.MASK PORTA.DIRECTION  SET.BITS  \ make PA5 an output pin

  HIGH.PULSE =

  IF PA5.MASK PORTA CLEAR.BITS  \ ensure that PA5 is LOW

SET.OUTPUT           \ push mask for HIGH transition

 ELSE  PA5.MASK PORTA SET.BITS \ ensure that PA5 is HIGH

CLEAR.OUTPUT         \ push mask for LOW transition

  ENDIF

   TCNT @ 10MS + TOC3 !       \ activate 1-shot after 10ms delay

 OC3.MASK TFLG1 C!       \ clear interrupt flag OC3F

  OC3.MASK  TMSK1 SET.BITS      \ set OC3I to enable interrupt

  TCTL1 SET.BITS          \ set bits accding to transition mask

;



With these words, it is possible to generate a single HIGH or LOW pulse of duration between 0.08 and 131.0 milliseconds.  The following command produces a 50 ms HIGH pulse:

HIGH.PULSE 50. ONE.SHOT

To verify that the output timer compare actually sent a 50. ms pulse, you can use the input capture pulse measurement routine defined in the “Input Signal Pulse Width Measurement” section above.  Connect a jumper between PA2 (IC1) and PA5 (OC3), then type the following:

HIGH.PULSE PREPARE.TO.MEASURE \ set up IC1 pulse width measurement

HIGH.PULSE 50. ONE.SHOT\ send a 50. ms pulse from OC3 to IC1

Send pulses of different length using ONE.SHOT.  After each call to ONE.SHOT, PULSE.WIDTH.MEASURER will report the duration of the pulse.  Sending a pulse of width less than 0.2 ms will be incorrectly reported as having a width of 131.1 ms.  This is due to PULSE.WIDTH.MEASURER’s latency which is approximately 0.2 ms.  PULSE.WIDTH.MEASURER would have to be modified slightly to measure shorter pulses.

With an 8 MHz crystal frequency, the 68HC11F1 and QED-Forth impose an interrupt latency of 27us (17us interrupt entrance latency, and 10us exit latency).  This typically limits the maximum achievable output signal frequency generated by an interrupt-driven output compare to about 10kHz.  If the QED Board is clocked at 16 MHz then pulse width modulated frequencies up to approximately 20 kHz can be generated by the processor.

Generating Synchronous Waveforms

Output compare 1 may be used to synchronously change any or all of PORTA pins PA3 through PA7. Whether a pin is modified, and to what state it is changed, depends on the configuration of two registers named OC1M (OC1 masks) and OC1D (OC1 data); see MC68HC11F1 Technical Data Manual,  pp.7-5...7-6, and M68HC11 Reference Manual, pp.10-33...10-36.  The OC1M register determines which PORTA pins should be affected by a successful compare of TOC1 and TCNT.  OC1D determines how the selected PORTA pins will be set.  A set bit in OC1D indicates that the corresponding PORTA pin will be set HIGH, and a clear bit in OC1D indicates that the PORTA pin will be cleared to a LOW state.  After determining which pins should be affected when TOC1 equals TCNT, the following steps must be completed to use output compare 1:

                                                                                                                                                                                           0.                                                                                                                                                                                           Set the state bits in bit positions 3-7 in the OC1 data register (OC1D).  Each bit that is set in OC1D causes the parallel PORTA bit to be set HIGH on a successful compare.  Likewise, clearing an OC1D bit causes the parallel PORTA bit to be set LOW on a successful compare.  Notice the correspondence between bit locations in registers PORTA and OC1D.

                                                                                                                                                                                           0.                                                                                                                                                                                           Determine the TCNT count when the desired state changes are to occur and store this value in the TOC1 register.

                                                                                                                                                                                           0.                                                                                                                                                                                           Clear the OC1F flag bit in the TFLG1 register by writing a 1 to the OC1F bit.

                                                                                                                                                                                           0.                                                                                                                                                                                           If an interrupt is to be called upon a successful compare of TCNT and TOC1, install the interrupt handler and enable the OC1I bit in the TMSK1 register.

                                                                                                                                                                                           0.                                                                                                                                                                                           Finally, enable the PORTA pins whose states should be affected by a successful OC1 compare by writing ones to each corresponding bit in the OC1 mask register, OC1M.  Notice the parallelism between bit locations in registers PORTA and OC1M.  It is important that by the time these bits are set, the count in TCNT has not reached the count stored in TOC1 in step 2.

To demonstrate the use of OC1’s synchronized output compare function, the following example implements a four-phase stepper motor controller using PORTA pins PA4, PA5, PA6, and PA7.

An Example: Synchronous Stepper Motor Control

A stepper motor turns clockwise or counterclockwise when its windings are energized.  A four-phase stepper motor has four windings that are energized using a predetermined sequence called a wave step sequence.  The speed of the motor’s rotation depends on the rate at which the wave step sequence is presented to the windings.  The sequence determines the speed, torque and rotational precision of the motor.  The following table specifies the 4-step sequence, and shows the pulse pattern associated with each phase.  Each phase/winding of the motor is driven by a PORTA output bit under the control of output compare 1.



When this sequence is iterated through steps 1...4, the motor turns in a clockwise direction. When stepped through in reverse order, 4...1, it causes the motor to turn counterclockwise.

The following code illustrates how to implement the clockwise wave step sequence using output compare 1 to control a 4-phase stepper motor.  Extending the code to handle counterclockwise rotation is left as an exercise for the interested reader.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

ANEW STEPPER.CONTROLLER        \ declare a forget marker

HEX

\ define the relevant control registers:

800C   REGISTER: OC1M        \ output compare 1 mask register

800D   REGISTER:   OC1D \ output compare 1 data register

800E   REGISTER: TCNT        \ timer count register

8016   REGISTER: TOC1        \ OC1 timer count register

8022   REGISTER: TMSK1       \ timer interrupt mask register 1

8023   REGISTER: TFLG1       \ timer interrupt flag register 1



80  CONSTANT OC1.MASK    \ used for OC1 interrupt flag & mask

F0   CONSTANT STEPPER.OUTPUTS   \ mask with bits 4-7 set



\ define constants to specify the step waveform:

   \  PA7   PA6   PA5 PA4

A0 CONSTANT 1ST.STEP      \ Step 1: HIGH  LOW  HIGH  LOW

60   CONSTANT 2ND.STEP \ Step 2: LOW  HIGH  HIGH  LOW

50   CONSTANT 3RD.STEP \ Step 3: LOW  HIGH  LOW  HIGH

90   CONSTANT 4TH.STEP \ Step 4: HIGH  LOW  LOW  HIGH



INTEGER: SPEED     \ a self-fetching variable that holds the #counts to add

           \ to the TOC1 count register. Inited by START.STEPPING



200.   FCONSTANT STEPS/REVOLUTION  \ this depends on your stepper motor

                    \ and the step waveform

5.0E5 FCONSTANT TICKS/SEC         \ # TCNT ticks per second



CODE STEP.CLOCKWISE ( -- )

\ this routine uses the contents of the OC1 data register (OC1D) to

\ determine which step of the waveform has just been set up, and updates

\ OC1D to set up the next step when OC1 is triggered the next time.

\ The routine puts the current contents of OC1D in accumulator A, and the

\ next contents of OC1D in accumulator B.  At the end of the routine it

\ stores the updated contents in accumulator B into OC1D.

  OC1D DROP EXT LDAA         \ A gets current OC1D contents

  1ST.STEP IMM CMPA

   EQ IF,                  \ if we’re on 1st step...

    2ND.STEP IMM LDAB    \ ...then 2nd step is next

   ELSE,

      2ND.STEP IMM CMPA

      EQ IF,               \ if we’re on 2nd step...

       3RD.STEP IMM LDAB \ ...then 3rd step is next

      ELSE,

         3RD.STEP IMM CMPA

         EQ IF,               \ if we’re on 3rd step...

          4TH.STEP IMM LDAB \ ...then 4th step is next

ELSE,             \ if we’re on 4th step...

          1ST.STEP IMM LDAB \ ...then 1st step is next

         THEN,

      THEN,

   THEN,

   OC1D DROP EXT STAB            \ put updated contents in OC1D

RTS                     \ return

END.CODE





CODE MOTOR.HANDLER ( -- )

\ this is the interrupt service routine for OC1.  It clears the interrupt flag,

\ updates the TOC1 timer compare register according to the contents of SPEED,

\ and calls STEP.CLOCKWISE to update the OC1 data register so that the

\ next step’s waveform will be output on PORTA pins 4-7 on the next

\ successful OC1 compare.

   OC1.MASK    IMM LDAA

 TFLG1 DROP  EXT STAA        \ clear the interrupt flag bit in TFLG1 register

  CALL SPEED ( -- #counts.to.add.to.TOC1 )

 0     IND,Y LDD      \ accumulator D now has #counts to add

   TOC1 DROP   EXT ADDD     \ D <- #counts + prior count = new count

 TOC1 DROP   EXT STD         \ store new count into TOC1 register

  2     IMM   LDAB

       ABY      ( -- )      \ drop the stack item

  CALL STEP.CLOCKWISE        \ update OC1D to do next wave change

           RTS \ return

END.CODE





: SET.SPEED ( speed.in.rpm -- | input is fp# = speed in revolutions/min )

\ stores the # ticks per step interval in the self-fetching variable SPEED

   60. F*         \ convert speed to revs/sec

  STEPS/REVOLUTION F* \ #steps/sec = revs/sec * steps/rev

   TICKS/SEC FSWAP F/ \ #ticks/step = ticks/sec  ÷  steps/sec

  UFIXX          \ convert to integer

  TO SPEED       \ store #ticks/step in SPEED

;





: START.STEPPING ( speed.in.rpm -- | input fp# = speed in revolutions/min )

\ initializes the self-fetching variable SPEED, ATTACHes motor handler routine,

\ initializes the OC1 configuration registers, and enables the OC1 interrupt

 0 OC1M C!                  \ turn OC1 actions off

 SET.SPEED ( -- ) \ init SPEED variable

 CFA.FOR MOTOR.HANDLER OC1.ID ATTACH \ attach the handler

   STEPPER.OUTPUTS PORTA.DIRECTION SET.BITS   \ PA4...PA7 are outputs

  1ST.STEP PORTA SET.BITS             \ energize outputs as 1st step

  2ND.STEP OC1D C!              \ init OC1D to do next step

  SPEED  TCNT @ + TOC1 !           \ set time for next step

  OC1.MASK TFLG1 C!          \ clear the OC1 flag

   OC1.MASK TMSK1 SET.BITS       \ enable OC1 interrupts

   STEPPER.OUTPUTS OC1M C!       \ set OC1 to control PORTA pins 4-7

ENABLE.INTERRUPTS          \ globally enable interrupts

;



: STOP.STEPPING ( -- )

  0 OC1M C!                  \ disconnect OC1 from PORTA pins

   OC1.MASK TMSK1 CLEAR.BITS        \ disable OC1 interrupts

  STEPPER.OUTPUTS PORTA CLEAR.BITS    \ force stepper outputs low

;

The words START.STEPPING and SET.SPEED provide the basis for controlling a stepper motor.  The PORTA signals PA7, PA6, PA5 and PA4 should be interfaced to the motor windings via current-boost buffers that are capable of driving inductive loads.  For smooth motor control, additional routines must be defined to ramp the motor from one speed to another.  If software is the only factor that limits motor performance, the controllable speed ranges from less than 2.5 rpm (limited by the 131 ms overflow time of the TCNT register) to over 2500 revolutions per minute (limited by the time required to execute the MOTOR.HANDLER interrupt service routine).

In the absence of a stepper motor, an oscilloscope can be used to verify the operation of the code in creating the desired waveforms.  For example, to see the waveforms needed to run the motor at 10. rpm, connect your scope probes to the PA4-7 outputs and execute

10. START.STEPPING

To see how the waveform changes when the speed is doubled, execute

20. SET.SPEED

To disable the output waveforms, type

STOP.STEPPING



Timesliced Multitasking and Output Compare 2

The timesliced multitasker uses OC2’s timer and interrupt to implement timed task switching and to maintain an elapsed-time clock as explained in the “Multitasking” chapter in the QED Software Manual.  Consequently, when using the timeslicer, you may not use OC2’s timer.  If you want to create an output on pin PA6 that is synchronized with the timeslice clock, configure OC2’s edge bits to toggle with each successful compare.

Even while the multitasker is running, you may use PA6 as an input or output.    OC1 can control PA6 while the timeslicer uses OC2’s timer.  Thus, the stepper motor controller described above may be used while the timesliced multitasker is running.

Forcing Output Compares

The 68HC11 allows you to immediately force a state change on a PORTA output pin that is being controlled by an output compare.  The compare force register named CFORC (M68HC11 Reference Manual,  pp.10-36...10-37) controls this function.  When an appropriate bit in CFORC is set, the output compare’s next scheduled state change is immediately forced upon the associated PORTA pin.  No interrupt is generated.

Force bits FOC1, FOC2, FOC3, FOC4, and FOC5 in the CFORC register correspond with output compares OC1, OC2, OC3, OC4, and OC5 respectively.  Whenever a 1 is written to any of these bits, the programmed transition on the corresponding output compare is forced to occur on the next count of the TCNT timer.  The output compare’s flag bit, OCxF, is not set, and an interrupt is not triggered.  After the forced signal change, the next transition/interrupt caused by the output compare occurs when TCNT equals TOCx (that is, when the next successful output compare occurs).  Depending on the value in TOCx, a match could occur at any time after a CFORC.  For this reason, it is uncommon to use CFORC to control a bit that is programmed to toggle with each successful compare.  This is because the forced change of state could be counteracted immediately by a successful output compare.

The following words may be used to force an output compare via the CFORC register.



HEX

800B  REGISTER:   CFORC \ define the compare force register



\ now assign names to the bit positions in the CFORC register;

\ each name indicates the output compare number and the affected PORTA bit(s)

80    CONSTANT FOC1/PA3-7

40    CONSTANT FOC2/PA6

20    CONSTANT FOC3/PA5

10    CONSTANT FOC4/PA4

08    CONSTANT FOC5/PA3

For example, the following command immediately forces OC3’s associated pin PA5 LOW if it has been configured to transition LOW on the next successful compare between TCNT and TOC3:

FOC3/PA5  CFORC SET.BITS



Summary of Output Compare Functions

The 68HC11F1 has 5 output compare functions named OC1, OC2, OC3, OC4, and OC5.  An output compare function allows the programmer to specify actions that are initiated when the contents of TCNT match the contents of a 16-bit TOCx register.  When these contents match, we say that a “successful output compare” has occurred.

Each output compare function has a 16-bit TOCx register, a successful compare OCxF (interrupt) flag, and an interrupt mask OCxI, where x is the output compare number.  Output compares OC2, OC3, OC4 and OC5 also have a pair of output mode/level bits, OMn and OLn, which determine the effect that each successful compare has on PORTA bits PA6, PA5, PA4, and PA3 respectively.  The processor sets an output compare’s OCxF flag bit when the contents of the TCNT register and its TOCx register are equal.  At the same instant, the state of the associated PORTA pin may be changed as specified by the output mode bits.  In addition, if the output compare’s OCxI mask bit is set, an interrupt is recognized when a successful compare occurs.

Output compare 5 operates like the other output compares; however, it must be initialized by clearing the I4/O5 bit of the PACTL (pulse accumulator control) register before it may be used.  IC4/OC5 and associated pin PA3 are used by the secondary serial port, so be sure not to use these resources if you need the second RS232 serial link.

Output compare 1 is special in that it can synchronously control any of PORTA pins PA7, PA6, PA5, PA4, and PA3.  Although OC1 may control several PORTA pins, the timer and interrupt functions of those output compares may still be used independently of the pin (to implement clocks, etc.)  Conversely, the timeslicer’s use of OC2’s timer and interrupt does not disallow control of the associated pin PA6 by OC1, nor does it disallow the use of PA6 as a general purpose digital input or output.

Using the CFORC register, it is possible to immediately force a state change on a timer-controlled signal without causing an interrupt.

The flexible output compare functions can be used to implement a stepper motor controller, pulse generator, pulse width modulated signals, timed output pulses, timesliced multiplexing, and internal clocks.

The Pulse Accumulator

The 68HC11F1 has an 8-bit counter/timer that may be configured either as a pulse accumulator or as gated timer.  The pulse accumulator can count pulses sensed on PORTA pin PA7.  The polarity of the edges that increment the accumulator may be programmed.  Interrupts can be optionally triggered when the 8-bit count overflows and when each pulse is detected.

The 8-bit gated timer is incremented every 32 us while a gating signal at pin PA7 is active. The gated timer facilitates pulse width measurement, synchronization of program execution using controlled delays, and discrimination of pulses which vary in width.

This section describes the operation of the pulse accumulator, and the next section describes the gated timer.

The pulse accumulator is incremented each time a specified signal transition is detected on PORTA pin PA7, which may be configured either as an input or an output.  Common pulse sources are motor encoders, analog to frequency converters, and switches. Using the pulse accumulator requires five steps:

                                                                                                                                                                                           0.                                                                                                                                                                                           Configure PORTA pin PA7 either as an input or an output as your application requires, and configure the subsystem for pulse accumulation.

                                                                                                                                                                                           0.                                                                                                                                                                                           Configure the pulse accumulator for either rising or falling pulse edges.

                                                                                                                                                                                           0.                                                                                                                                                                                           If interrupts will be used to service pulse accumulator overflows or sensed pulse edges, install appropriate interrupt service routines.

                                                                                                                                                                                           0.                                                                                                                                                                                           Store an initial count into the pulse accumulator register.

                                                                                                                                                                                           0.                                                                                                                                                                                           Enable the pulse accumulator.

The configuration and enabling of the pulse accumulator is controlled via three bits in the pulse accumulator control register PACTL (M68HC11 Reference Manual,  pp.11-2...11-6, MC68HC11F1 Technical Data Manual,  p.7-12).  The three bits are:



To configure PORTA pin PA7 for pulse accumulation, the PAMOD (pulse accumulator mode) bit must be clear in PACTL.

If PEDGE is clear, falling edges are counted, otherwise rising edges are counted:



Once the pulse accumulator is configured, it is enabled by setting the pulse accumulator enable bit PAEN.  Before this is done, however, it is sometimes desirable to initialize the pulse accumulator count and set up one or both of the associated interrupt handlers.

When the pulse accumulator is enabled, its count is incremented each time the specified pulse edge is sensed.  The 8-bit pulse accumulator count is stored in a register named PACNT (MC68HC11F1 Technical Data Manual,  p.7-13).  PACNT can be read and written without restriction, and it is not affected by a reset.  Since it is 8-bits wide, it can count from 0 to 255 before overflowing to 0.  When an overflow occurs, the pulse accumulator overflow flag, PAOVF, is set in the timer flag register TFLG2 (MC68HC11F1 Technical Data Manual,  p.7-10).  This flag bit is paired with an interrupt mask named PAOVI found in the timer mask register TMSK2 (MC68HC11F1 Technical Data Manual,  p.7-9).  These bits may be used to implement an interrupt handler for pulse accumulator overflows.

Typical uses for the pulse accumulator overflow interrupt are to increase the number of countable pulses by incrementing a 16-bit variable each time the counter overflows, or to notify the programmer when a predetermined number of pulses has been received.  For example, to trigger an interrupt after n pulses have been detected, initialize the PACNT register to 256-n and enable the overflow interrupt (see M68HC11 Reference Manual,  pp.11-6...11-7 for more details).

It is possible to recognize an interrupt after each detected pulse edge.  The pulse accumulator input-edge interrupt flag PAIF in the TFLG2 register is set whenever an input edge is detected.  Its corresponding interrupt mask is named PAII, and is located in the TMSK2 register.

After installing the interrupt handlers needed for your implementation of the pulse accumulator, you may want to initialize the PACNT register using a C! command before enabling the subsystem.  As you will see in the example below, the pulse accumulator is very easy to use.

Words to Configure the Pulse Accumulator

The following utilities configure the pulse accumulator control and status bits:

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

HEX

8024 REGISTER: TMSK2 \ timer interrupt mask register 2

8025 REGISTER: TFLG2 \ timer interrupt flag register 2

8026 REGISTER: PACTL \ pulse accumulator control register

8027 REGISTER: PACNT \ pulse/time count register



40 CONSTANT PAEN        \ pulse accumulator/gated timer enable bit

20 CONSTANT PAMOD \ mode select bit, clear selects pulse accumulator

10 CONSTANT PEDGE \ signal edge trigger/gate configuration bit

20 CONSTANT PAOVF \ PACNT overflow flag bit

10 CONSTANT PAIF \ trigger/gate sense flag bit

20 CONSTANT PAOVI \ interrupt enable bit for PACNT overflows

10 CONSTANT PAII \ interrupt enable bit for edge detection



\ the following 2 edge.sense.ids are used as inputs to INIT.PULSE.ACCUMULATOR:

1  CONSTANT RISING.EDGE \ to increment counter on rising edge

2  CONSTANT FALLING.EDGE   \ to increment counter on falling edge



: INIT.PULSE.ACCUMULATOR ( edge.sense.id -- )

   CASE

      RISING.EDGE OF PEDGE PACTL SET.BITS    ENDOF

      FALLING.EDGE   OF PEDGE PACTL CLEAR.BITS  ENDOF

      CR .” You must specify either RISING.EDGE or FALLING.EDGE.”

      ABORT

   ENDCASE

   PAMOD PACTL CLEAR.BITS  \ set mode for pulse accumulation

;



: ENABLE.PULSE.ACCUMULATOR ( -- )

   PA7.MASK PORTA.DIRECTION CLEAR.BITS \ PA7 is an input

   PAOVF PAIF OR TFLG2 C!     \ clear both interrupt flags

   PAEN PACTL SET.BITS        \ enable the pulse accumulator

;



: DISABLE.PULSE.ACCUMULATOR ( -- )

   PAEN PACTL CLEAR.BITS      \ clear the pulse accumulator enable bit

;

To count either rising or falling edge pulses using the pulse accumulator, type one of the following:

RISING.EDGE INIT.PULSE.ACCUMULATOR

FALLING.EDGE INIT.PULSE.ACCUMULATOR

Then to enable the system type:

ENABLE.PULSE.ACCUMULATOR

And finally, to disable the system:

DISABLE.PULSE.ACCUMULATOR

To read the 8-bit number of counted pulses, execute

PACNT C@

Extending the Range of the Pulse Accumulator

Interrupts are available to monitor pulse accumulator overflow and input edge detection.  The following example uses an interrupt handler to extend the number of pulses that can be counted.  The code relies on definitions presented in the previous section.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

VARIABLE #PULSE.OVERFLOWS        \ number of PACNT overflows



: PAOVF.HANDLER ( -- )            \ interrupt handler for overflows

  PAOVF TFLG2 C!          \ clear PAOVF flag

  1 #PULSE.OVERFLOWS +!         \ increment the number of PACNT overflows

;



: INIT.EXTENDED.PULSE.ACCUMULATOR ( edge.sense.id -- )

  \ input is either RISING.EDGE or FALLING.EDGE

   PAOVI TMSK2 CLEAR.BITS     \ disable PACNT overflow interrupt

   CFA.FOR PAOVF.HANDLER PULSE.OVERFLOW.ID

ATTACH                     \ install handler

INIT.PULSE.ACCUMULATOR     \ initialize pulse accumulator

   0 PACNT C!                 \ set pulse accumulator count to 0

   0 #PULSE.OVERFLOWS !       \ set overflow count to 0

   PAOVI TMSK2 SET.BITS       \ enable PACNT overflow interrupt

  ;



: #PULSES ( -- n | n = total number of pulses sensed since initialization )

   \ each pulse overflow represents 100H pulses.  The total number of pulses

   \ equals the pulses represented by the overflows plus the number of pulses

   \ since the last overflow (which is simply the contents of PACNT).

   #PULSE.OVERFLOWS @ 100 * PACNT C@ +

;

The pulse accumulator can now count over 16 million pulses before the #PULSE.OVERFLOWS variable overflows.  To prepare the system to count pulses triggered on rising edges type:

RISING.EDGE INIT.EXTENDED.PULSE.ACCUMULATOR

Executing #PULSES now reveals that no pulses have been detected yet.  To begin sensing pulses type:

ENABLE.PULSE.ACCUMULATOR

If a pulse source is present at PORTA pin PA7, executing #PULSES reveals the number of pulses that have been detected.  To disable the pulse accumulator type:

DISABLE.PULSE.ACCUMULATOR

Summary of the Pulse Accumulator

There are many interesting uses for the pulse accumulator, and its operation is straightforward.  To accumulate pulses sensed at pin PA7, clear the PAMOD bit in the PACTL register.  Set PEDGE in PACTL for rising edge detection, or clear it for falling edges.  If interrupts are used to handle PAOVF or PAIF flags, install interrupt handlers and set the PAOVI or PAII bits in TMSK2 to enable the interrupts.  As always, each interrupt handler must reset its interrupt flag by writing a one to the flag bit.  Write an appropriate initial value to the 8-bit count register PCNT and then enable the pulse accumulator by setting the PAEN bit in PACTL.  The example above demonstrates how the pulse accumulator overflow interrupt facilitates counting more than 255 pulses.

The Gated Timer

The gated timer subsystem provides an easy way to measure pulse widths, time external events, and discriminate between pulses with differing widths.  It is configured and controlled by the same registers and control bits used by the pulse accumulator.   PORTA pin 7 is used as a timer gating signal.  The gate signal’s active state is determined by the pulse edge bit PEDGE in the pulse accumulator control register PACTL.  When the PA7 gating signal is active, the pulse accumulator count register PACNT is incremented every 64th E-clock cycle, which is equivalent to 32us per count with an 8 MHz crystal and 16 us per count with a 16 MHz crystal.  Interrupts may be triggered when the gated timer count overflows, and/or when the trailing edge of the timer gate signal is detected.

Implementation of the gated timer subsystem follows the same five steps used by the pulse accumulator. To configure PORTA pin 7 for gated timer use, set PA7 as an input or output by writing to the PORTA.DIRECTION register, and set the PAMOD bit in the pulse accumulator control register PACTL.

The PEDGE bit in the PACTL register determines the gate signal’s inactive, or inhibiting, state.  If PEDGE is clear, the PACNT register is inhibited from advancing while PA7 is LOW (in other words, the gating signal is active high).  If PEDGE is set, the PACNT register is inhibited while PA7 is HIGH (in other words, the gating signal is active low).

Setting the PAEN (pulse accumulator enable) bit enables the gated timer.  Once enabled, the PACNT register is incremented every 32us (if the crystal frequency is 8 MHz) while the gating signal at PA7 is active.

Interrupts are triggered and controlled by the same flag and mask bits used by the pulse accumulator.  The pulse accumulator overflow flag (PAOVF) is set whenever pulse accumulator count register PACNT overflows.  An overflow interrupt is recognized if the overflow interrupt mask PAOVI is also set.

The pulse accumulator input flag PAIF is set by the processor whenever the trailing edge of the gating signal on PA7 is detected.  If the associated interrupt mask PAII is also set, an interrupt is recognized.  To measure a pulse width using this interrupt, it is common to clear PACNT, install a pulse accumulator edge interrupt handler by executing

CFA.FOR <name of interrupt handler>  PULSE.EDGE.ID  ATTACH

and then enable the gated timer subsystem.  PACNT is then incremented every 32us (for an 8 MHz crystal) while the input gating signal is active.  At the trailing edge of the input signal, a PAIF interrupt is recognized and the interrupt handler can read and reset PACNT.  The PACNT reading multiplied by 32us is the pulse width of the timer gate signal in microseconds.

Words to Configure the Gated Timer

The following utility words configure the gated timer subsystem.  This code relies on definitions presented in the Pulse Accumulator section.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

\ the following 2 constants are used as inputs to INIT.GATED.TIMER:

1  CONSTANT HIGH.PULSE     \ for measuring an active HIGH pulse

2  CONSTANT LOW.PULSE      \ for measuring an active LOW pulse





: INIT.GATED.TIMER ( gate.pulse -- )

   CASE

      HIGH.PULSE  OF PEDGE PACTL CLEAR.BITS  ENDOF

      LOW.PULSE   OF PEDGE PACTL SET.BITS ENDOF

      CR .” You must specify either HIGH.PULSE or LOW.PULSE.”

      ABORT

   ENDCASE

   PAMOD PACTL SET.BITS    \ mode is gated timer

;



: ENABLE.GATED.TIMER ( -- )

ENABLE.PULSE.ACCUMULATOR

;



: DISABLE.GATED.TIMER ( -- )

DISABLE.PULSE.ACCUMULATOR

;

Measuring Pulse Widths Using the Gated Timer

The following example demonstrates how to use the gated timer subsystem to measure a pulse width.

Listing 80                                                                                                                                                                                           Enter your Listing Caption here.

DECIMAL

32 CONSTANT USEC/TICK \ 1 clock tick equals 32 usec at 8 MHz crystal freq.



\ Computes and prints the width of the detected pulse in microseconds.

: SAY.PULSE.WIDTH ( -- )

   PACNT C@          \ get the number of ticks in PACNT

   #PULSE.OVERFLOWS @ 256 * + \ get additional ticks from overflows

   USEC/TICK * \ total usec=(PACNT+(#OVERFLOWS*256))*32us/tick

   .” Pulse width = “ . .” usec.”

;



\ This is the interrupt service routine for the pulse accumulator

\ edge detection interrupt.  It is executed at the trailing edge of the gate signal,

\ which corresponds to the time when the gated timer has just finished counting.

\ This handler disables the pulse accumulator interrupts so that no further

\ counting will be done.

: TRAILING.EDGE.HANDLER ( -- )

DISABLE.PULSE.ACCUMULATOR     \ disable counting

   PAIF TFLG2 C!           \ clear PAIF flag

   PAOVI PAII OR TMSK2 CLEAR.BITS   \ disable PAOVI & PAII interrupts

;



\ INIT.GATED.PULSE.TIMER uses the PACNT register overflow interrupt

\ handler defined earlier to extend the range of measurable pulse

\ widths beyond 256*32 usec.  INIT.GATED.PULSE.TIMER clears

\ the relevant count variables, configures the gated timer subsystem,

\ installs the overflow and trailing edge interrupt handlers defined above,

\ and enables the overflow and pulse edge interrupts, and the gated timer.

: ENABLE.GATED.PULSE.TIMER ( gate.pulse -- )

   PAOVI PAII OR TMSK2 CLEAR.BITS   \ disable PAOVI & PAII ints.

   0 PACNT C!              \ clear the PACNT register

   0 #PULSE.OVERFLOWS !       \ clear PACNT overflow count

   INIT.GATED.TIMER \ init gated timer

   CFA.FOR PAOVF.HANDLER        PULSE.OVERFLOW.ID ATTACH

   CFA.FOR TRAILING.EDGE.HANDLER   PULSE.EDGE.ID         ATTACH

   PAOVI PAII OR TFLG2 C!        \ clear interrupt flags

   PAOVI PAII OR TMSK2 SET.BITS     \ enable PAOVI & PAII interrupts

   ENABLE.GATED.TIMER

;

After connecting a pulse signal source to PORTA pin PA7, executing the following words will measure the source’s HIGH pulse width:

HIGH.PULSE ENABLE.GATED.PULSE.TIMER

After the pulse, execute

SAY.PULSE.WIDTH

to display the calculated pulse width.

The Real-Time Interrupt Function

The real-time interrupt (RTI) function provides a periodic time reference signal.  It may be used in applications which require an action to be reliably performed on a regular basis.  For example, the RTI is a convenient way to ensure that the computer operating properly (COP) subsystem is periodically serviced.

The RTI function triggers a periodic interrupt.  Two rate bits, RTR0 and RTR1 in the PACTL register program the real-time interrupt period according to the following table (MC68HC11F1 Technical Data Manual,  pp.7-12...7-13, M68HC11 Reference Manual, pp.10-11...10-12):

Table 8‑5                                                                                                                                                                                           Enter your Table Caption here.

Each time the RTI period has elapsed, the processor sets the RTIF interrupt flag in the TFLG2 (timer flag 2) register.  If the interrupt mask bit RTII in TMSK2 is also set, an interrupt is recognized.  As with all interrupts, it is very important that the RTI’s interrupt handler reset the interrupt flag by writing a one to it.

If the RTI periods do not suit your application, a timer based on an output compare function can be used to perform a similar service (as demonstrated in the OC1 alarm example presented earlier in the chapter).  Given the simplicity of the RTI function, its implementation is left as an exercise to the interested reader.

Programmable Timer and Pulse Accumulator Summary

The programmable timer and pulse accumulator may be used to implement timesliced multitasking, clocks, programmable waveform generation, pulse width measurement and discrimination, control of stepper motors, external event counting, and many other interesting applications.

The explanations and commented code examples presented in this chapter demonstrate how to configure, initialize, and enable each of the timing and counting functions.

The Processor’s Output Compare Functions

The processor’s programmable timer subsystem contains 5 output compare (OC) functions (named OCx for x from 1 to 5) associated with PORTA output pins PA7 through PA3 (in descending order).  These output compare functions allow you to specify actions that take place at particular, well determined times.  Using output compares, it is easy to set up real-time clocks, cause periodic execution of code, and generate precisely timed synchronous or asynchronous waveforms.  They can be used to implement a stepper motor controller, pulse generator, pulse width modulation (PWM) signals, precisely timed output pulses, timesliced multiplexing, or serial communications.

Output-compare functions work by automatically changing PORTA output pins and/or invoking an interrupt service routine (ISR) whenever the contents of a free-running 16-bit counter (TCNT) matches the contents of user-set output-compare registers, TOCx.  When these contents match, we say that a “successful output compare” has occurred.  Thus the programmer can precisely specify a future time at which an action will occur by simply storing the time as a 16-bit value in the appropriate output compare register, TOCx. The free running counter counts at a programmable rate, from 0 to 65536, then rolls over to zero and continues counting.  Its rate is one count each 2 microseconds, for a rollover period of 131.072 milliseconds.  Consequently, you can set up output compares to trigger events with a resolution of 2 microseconds, and up to 131.072 milliseconds into the future (or arbitrarily longer if you keep track of rollovers on TCNT).

Because TCNT is clocked by a prescaler driven from the system E clock, you can change the count rate by modifying the prescaler’s division ratio, from its current value of 8 to 1, 4, or 16, changing its rollover period to 16.384, 65.536, or 262.144 milliseconds.  If you do though, the system timeslicer will be affected.  We find that a 2 microsecond tick rate provides sufficient resolution for most applications.

Each of the five output compare subsystems has a 16-bit TOCx register, a successful compare OCxF (interrupt) flag, and an interrupt mask OCxI, where “x” is the output compare number.  OC1 can control any of pins PA3 through PA7 and it has its own register to specify which of PORTA pins are affected.  Output compares OC2, OC3, OC4 and OC5 each control a single pin. They each have a pair of output mode/level bits, OMn and OLn, which determine the effect that each successful compare has on PORTA bits PA6, PA5, PA4, and PA3 respectively.  The processor automatically sets an output compare’s OCxF flag bit in the TFLG1 register when the contents of the TCNT register and the OC’s TOCx register are equal.  At the same instant, the state of the associated PORTA pin is set, cleared, or toggled as specified by the output mode bits.  In addition, if the output compare’s OCxI mask bit in the TMSK1 register is set, an interrupt is recognized when a successful compare occurs.

An active output compare function can cause a signal change on a PORTA pin at a specified time T, and/or trigger an interrupt at time T:

  Signal Change – To cause a signal change on a PORTA pin when time T equals the contents of TCNT, the PORTA pin must be configured as an output, and the output compare function must be enabled.  OC1 is enabled by storing the data to be output in OC1D and specifying the pins to be changed in OC1M, and OC2-OC5 are enabled simply by storing a 2-bit code into TCTL1 specifying the desired signal change.  Using the CFORC register, it is also possible for software to immediately force a state change on a timer-controlled signal without causing an interrupt.

  Interrupt – To trigger an interrupt when time TCNT = T, an interrupt handler must be installed, and the output compare’s local interrupt must be enabled by setting bits in TMSK1.

Table 8‑6      Output Compares and their properties

Output Compare

Controlled PORTA Pin

Comparison Register

Comments and Alternate Use

OC1

PA3, 4, 5, 6, and/or 7

TOC1

May control multiple pins simultaneously, or be paired with another OC to jointly control pin PA3, 4, 5, or 6.

OC2

PA6

TOC2

The OC2 timer is used by the kernel’s  timeslicer and elapsed time clock functions.  If you do not use these functions, pin PA6 may be controlled by OC1 or used for general purpose I/O.

OC3

PA5

TOC3

Not used by the kernel.

OC4

PA4

TOC4

Used as an output by the secondary serial port.  Available if you do not need Serial 2.

OC5

PA3

TI4O5

Shared with Input Capture 4, which is used as an input by the secondary serial port.  Available if you do not need Serial 2.

As summarized in the table, the output compares are not all identical in function, and some are used by the operating system.  OC1 and OC5 differ from the others slightly in function, OC2 is used by the operating system’s timeslicer, and OC4 and OC5 are used by the secondary serial port:

  OC1 is special in that it can synchronously control any of PORTA pins PA7, PA6, PA5, PA4, and PA3.  Even when OC1 is used to control several PORTA pins, the timer and interrupt functions of those pin’s output compares may still be used independently of the pin (to implement clocks, etc.).  While the other output compares can be used to set, clear, or toggle an output pin, OC1 can be used only to set or clear a pin, but not to toggle it.

  OC2 is used by the timeslicer.  Consequently, if you need the services of the timeslicer (timesliced task switching, elapsed time clock, or BENCHMARK: function) make sure that you do not use OC2 for other functions.  Even if you do use the timeslicer, pin PA6 is still available for use as general purpose I/O, or as an output controlled by OC1.

  OC4 is used as an output by the secondary serial port, so you can’t use it or its associated pin PA4 if you need the second RS232 serial link.

  OC5 shares its timer register and output pin with input capture 4 (IC4).  OC5 operates like the other output compares, but it must be initialized by clearing the I4/O5 bit of the PACTL (pulse accumulator control) register before it may be used.  Also, IC4/OC5 and associated pin PA3 are used by the secondary serial port, so be sure not to use these resources if you need the second RS232 serial link.

Pulse and PWM Generation Techniques

The processor’s output compare functions provide lots of flexibility for creating single pulses or pulse-width-modulated waveforms. Most methods are variations on this algorithm:

    1. The desired start time of the pulse is programmed by storing an appropriate count in the output-compare register (TOCx) of OCx, and the OCx interrupt is enabled by setting a flag bit in TMSK1.

    2. OCx’s mode/level bits (OMx and OLx) are configured to automatically set the output compare’s corresponding output either high or low, depending on the polarity of the desired pulse (this action enables the output compare).

    3. When the compare occurs, the pin state is automatically changed and an interrupt service routine called.

    4. The interrupt service routine (ISR) reprograms the output compare to automatically change its pin back to its inactive level on the next compare;

    5. The ISR also increments the output-compare register by a value corresponding to the desired duration of the pulse.

Since the pin-state is changed by hardware automatically at specific values of the free-running counter, the pulse width is controlled accurately to the resolution of the free-running counter irrespective of software latencies.  By repeating the actions for generating a pulse, you can generate an output signal of a specific frequency and duty cycle.  While software latency and execution times do not affect the timing of the waveform, they do impose limits on the frequency and duty cycles attainable.  The different methods of generating PWM signals differ primarily on where the software execution times are constrained to fit, either within the on time, the off time, or the waveform’s period as a whole.

The following is a quick summary of some of some specific ways you can use output compares to generate pulses or PWM waveforms.  You can find complete descriptions of the registers mentioned in Motorola’s MC68HC11F1 Technical Data Manual.  Example 1 shows you how to generate a tirggered pulse, Examples 2 and 3 represent exceptional and instructive methods of generating PWM signals, and examples 4-6 are commonly used PWM methods.  Example 6 provides code for generating “failsafe” PWM signals.

Example 1 – Creating a Single Precise Pulse from an External Trigger

Suppose you’d like to output a single pulse on PA5 with very precise duration in response to a triggering event, for example the leading edge of an input pulse on PA0.  You’d like the output pulse to start a precise, fixed time after the initiating trigger and to last some precise duration, between 2 microseconds and 131 milliseconds.  Further, the output pulse should occur after the first occurrence of the trigger (after enabling the system) and then stay off rather than being retriggered by subsequent input pulses.

To do this you would use one input capture (IC3) and two output compares (OC1 and OC3).  Because the trigger may occur anytime an input capture is used to determine the precise time of its leading edge.  And because the output pulse width must be precisely controlled, and its duration can potentially be shorter than any interrupt service routine, the pulse should be turned on and off by output compares.  The input capture invokes an interrupt service routine that enables the output compares.  For our example we’ll assume the desired pulse start time is 10 milliseconds (or 5000 TCNT counts) after the trigger is detected, and its duration is precisely 10 microseconds (5 TCNT counts).  Here’s one way to do it using three routines:

     An initialization routine (called ENABLE) that configures and enables IC3 to capture a rising edge on PA0, forces PA5 off to initialize it, and configures and enables OC3 to turn off pin PA5;

     An interrupt service routine for IC3 (called IC3_ISR) that programs the comparator registers of OC1 and OC3 and enables OC1; and,

     An interrupt service routine for OC1  (called OC1_ISR) that disables OC1 so that after the output pulse is first turned on it is not turned on again.

Here’s how to write the routines:

ENABLE – Inhibit IC3, OC1, and OC3 interrupts by storing 0x0xxxx0 to TMSK1 (using CLEAR.BITS with a mask of 0xA1).  Configure OC1 to set PA5 high on an output compare by setting bit 5 of OC1D, but don’t enable it using OC1M yet – the IC3_ISR will be responsible for doing that. Configure OC3 to clear its associated pin (PA5) on an output compare by storing appropriate mode/level bits (OM3 and OL3), that is xx10xxxx, into the timer control register (TCTL1).  Initialize PA5 to the OFF state by forcing an early output compare on OC3.  This is done by setting bit 5 of CFORC.  Configure and enable IC3 to capture a rising edge PA0.  This is done by clearing bit 0 of DDRA (to set the data direction of PA0 to input), and setting the lower two bits of TCTL2 (the two corresponding to IC3) to xxxxxx01 to capture a rising edge. Clear the interrupt flag bit (IC3F) left over from any prior edge detection, if any, by writing a one to IC3F in TFLG1.  Finally, enable an IC3 interrupt by setting the IC3I bit in TMSK1.

IC3_ISR – On entering the ISR routine first disable further interrupts by clearing the IC3I bit in TMSK1, and clear the interrupt flag bit (IC3F) by writing a one to IC3F in TFLG1.  Then read TIC3 to determine the trigger time, we’ll call it TT.  Set up OC1 to turn on output pin PA5 at time TT+5000 by setting TOC1=TT+5000 and configure OC3 to turn it back off just 5 counts later, by setting TOC3=TT+5000.  Enable an OC1 interrupt by setting the OC1I bit in TMSK1.  Finally enable OC1 and tie it to PA5 by setting bit 5 in OC1M.

OC1_ISR – This interrupt service routine will be invoked when the output pulse is turned on.  It only needs to disable OC1 so that further pulses are not produced until the system is re-enabled by executing ENABLE again.  Disable OC1 by clearing bit 5 in OC1M.  Disable interrupts on OC1 by first clearing the OC1I bit in TMSK1, then clear the interrupt flag bit (OC1F) by writing a one to OC1F in TFLG1.

Example 2 – Two OCs Generate a PWM Waveform Without Interrupts

Using two output compares you can generate a PWM waveform of any duty cycle (from 1/65536 to 65535/65536) without using interrupt service routines.  As no ISR is used, no software resources are needed to maintain the waveform, and there is no impact on overall system performance.  The PWM waveform is free – from a software perspective.  So what’s the catch?  The catch is that the waveform must have a fixed period, equal to the rollover period of the free-running counter, or 131.072 milliseconds.  If you can live with that, here’s how it’s done:  Two output compares are used, one sets the output pin at a particular value of TCNT, and the other simply resets the pin at another TCNT value.  One of the output compares must be OC1 –  because it can be used in conjunction with another to control the same pin.  Let’s use OC1 to turn ON an output pin (PA5) whenever TCNT hits 0x0000, and OC3 to turn it OFF whenever TCNT hits 0x1000.  More specifically,

    1. Disable interrupts caused by OCs by storing 0x00 to the timer interrupt mask register 1 (TMSK1).  Now, output compares will not cause interrupts.  Even so, they can still control output pins.

    2. Use OC3 to turn OFF the pulse whenever TCNT=0x1000 (for example, for a duty cycle of 1/16) by storing 0x1000 into TOC3.  Configure OC3 to clear its associated pin (PA5) on a successful compare by storing appropriate mode/level bits (OM3 and OL3), that is xx10xxxx, into the timer control register (TCTL1).  Now, whenever TCNT hits 0x1000 pin PA5 will be cleared.  We configure the OFF transition first because we don’t want the pin to get stuck ON before we’re done configuring our output compares, just in case.

    3. Use OC1 to turn ON the pulse whenever TCNT=0x0000 by storing 0x0000 into TOC1.  Associate OC1 with pin PA5 by setting bit 5 in the output compare mask register OC1M.  Configure OC1 to set the pin high by storing 0x20 into the OC1 data register, OC1D.  Now, whenever TCNT hits 0x0000 pin PA5 will be set high.

Because an ISR isn’t used, there is no possibility of software delays influencing the PWM output.

Advantages: Precise transition time control, all duty cycles possible with 16-bit resolution, no software needed to keep things running, failsafe in that a software crash is not likely to affect operation.

Disadvantages: Only a single channel, only a single PWM period.

Example 3 – A Single OC-Driven ISR Generates Many PWM Channels

What if you want to generate many channels of PWM waveforms, more than there are output compares?  In the prior example output compares were used to generate a precisely-timed high-resolution waveform on a single channel without the assistance of an ISR.  This example provides the other extreme, an unlimited number of channels of low-resolution PWM signals are generated by a single output-compare-driven interrupt service routine.

The scheme uses a single output compare to periodically invoke an interrupt service routine.  The OC is not tied to a PORTA pin, rather it is used only as a dedicated clock that calls the ISR at a fixed interval corresponding to the smallest ON or OFF time that can be produced.  Each time the ISR is called it updates all the PWM outputs using any general purpose output pins available.  It may do this by reading values from a look-up table, counting, or more computationally.

Because the ISR latency can vary depending on what other interrupt-driven services are running on the controller there is some jitter (or variance) on the transition times, producing a slightly varying PWM duty cycle.  This variation can be compensated on the average if the ISR reads TCNT to determine the actual ON and OFF times and modulates the next ON or OFF time to attain the desired PWM duty cycle averaged over a number of cycles – but of course that requires greater execution time.

The sum of the ISR latency and execution times must be less than the difference between adjacent OC times, placing a limit on the smallest ON or OFF time attainable.  If the ISR is delayed so long that the next OC time is missed, the next ISR doesn’t occur until TCNT rolls over and another match occurs.  Consequently rollover delays of a TCNT period may be inserted into the desired ON or OFF times.

For an example of software generated PWM signals with 8-bit resolution and best averaging properties see “MI-AN-056 Optimal PWM Algorithm” and “MI-AN-058 Using Port PPA for PWM”.

Advantages: Any number of channels can be accommodated.

Disadvantages: ISR latency causes jitter in the transition times; ON or OFF times smaller than the ISR latency and execution time are not possible; rollover delays possible if timing criteria not met; not failsafe.

Example 4 – One OC and ISR Generates a “No Jitter” PWM Signal

The simplest way of generating a precise PWM waveform with arbitrary duty cycle and period is to use a single output compare to automatically turn on and off an output pin and an interrupt service routine that reprograms the output compare after each transition.  The “off” transition invokes the ISR which sets up the turn-on time and programs the next output state to be “on”, and the “on” transition invokes the same ISR to set up the turn-off time and the next “off” state.  The on and off times must each be great enough to contain the latency and execution time of the ISR.  So duty cycles that would require very small on or off times are not attainable.  If the ISR is delayed so that it does not program the next transition in time, than the output compare doesn’t find a match until TCNT rolls all the way around.  In this case rollover delays of approximately 131 msec may be inserted into either the on or off time.

Advantages: Transitions are precise, with no jitter; duty cycle and period are programmable over a wide range.

Disadvantages: ON or OFF times smaller than the ISR execution time and latency are not possible; rollover delays are possible; not failsafe – a software crash can leave the output stuck ON.

Example 5 – Two OCs and ISRs Generate a “No Jitter” PWM Signal of any Duty Cycle

To obtain ON and OFF times that may be each as small as a single clock tick, two OCs and ISRs are required.  The “off” transition invokes an ISR which sets up the next turn-off time, and the “on” transition invokes a different ISR to set up the next turn-on time.  Each ISR simply increments the next ON or OFF comparison register by the period.  There is no particular restriction on the shortness of the ON or OFF times, either can extend down to just a single count of TCNT, but their sum, the period, must be great enough to contain the latency and execution times of both ISRs.  Because OCs are used to drive the output pin, the transition times are exact, with no jitter.  If service of either ISR is delayed for more than a period then a rollover delay may be inserted into either the on or off time.

Advantages: Transitions are precise, with no jitter; duty cycle and period are programmable over a wide range, duty cycle extends fully from 1/65536 to 65535/65536.

Disadvantages: Rollover delays are possible; not failsafe – a software crash can leave the output stuck ON.

Example 6 – One OC and ISR Generates a “Failsafe” PWM Signal

A single OC and associated ISR is used.  The OC invokes an ISR for each transition.  For the ON transition, the ISR is responsible for setting the output pin.  It also computes the next turn-off time based on the time at which the pulse is actually turned on, and programs the OC to automatically turn it back OFF at the turn-off time.  At the next OC the pin is turned off by hardware and the ISR is again called.  This time the ISR just sets the turn-on time for the next OC time, disconnecting the OC from the pin so that the pin is not automatically set.  This sequence of events produces pulses whose duration is invariant with respect to ISR delay, but that may jitter back and forth within their fixed period.  Despite any jitter, the duty cycle and period are both precisely controlled.  If the ISR is delayed by more than the off time, rollovers are inserted into only the off time, never the on time.  So the pulse on times are failsafe so long as the processor’s clock is running.

Advantages: Failsafe operation assures an ON pulse is never longer than desired and the pulses turn off on a software crash.  ON time may be as small as a single TCNT count.

Disadvantages: Pulse position jitter; rollover delays are possible in the OFF time; minimum OFF time must be greater than the IST latency and execution time.

Table 8‑7      PWM Methods.

Method

ISR Used

Output Compares

Turn ON/OFF

Jitter

D.C. Accuracy

D.C. Range

Rollovers inserted?

Period

2

no

OC1 and one other

OC/OC

none

perfect

any

no – failsafe

Fixed at 131.072 ms

3

yes

any OC

ISR/ISR

yes

limited by ISR delays

Ton, Toff >ISR

yes

on and off times must each be greater than ISR latency and execution times

4

yes

any OC

OC/OC

no

perfect

Ton, Toff >ISR

yes

on and off times must each be greater than ISR latency and execution times

5

yes

OC1 and one other

OC/OC

no

perfect

Ton, Toff unlimited

yes

P>ISR1+ISR2

6

yes

any OC

ISR/OC

yes

perfect

Ton unlimited, Toff>ISR

failsafe –  into only the off time





<< Previous | Next>>


Home|Site Map|Products|Manuals|Resources|Order|About Us
Copyright (c) 2006 Mosaic Industries, Inc.
Your source for single board computers, embedded controllers, and operator interfaces for instruments and automation
