The Prototyping Wildcard™ filters or conditions the I/O lines of other Wildcards.

prototyping board for custom circuits

The Prototyping Wildcard is a general purpose, sea-of-holes printed circuit board you can use to prototype custom circuitry. It provides power supply rails and several convenient I/O connectors. It may be mounted on any of Mosaic's Controllers, Docking Panels or PowerDock and derives its power from the Wildcard Bus.

Prototyping Wildcard Connectors and Power Rails

Documentation and Pricing
